Build you Computer Vision Application – Part III: Pothole detector from scratch using legacy methods (Image Pyramids and sliding window)

This is the third post of the series were we build a road sign and pothole detection application. We will be using multiple methods through out this series which includes computer vision techniques using opencv, annotating images using labelImg, mastering Tensorflow object detection API, Training objection detection using transfer learning, Object detection on video etc. This series will be split across 9 posts.

1. Introduction to object detection

2. Data set preperation and annotation Using labelImg

3. Building your object detection model from scratch using Image pyramids and Sliding window ( This post )

4. Building your road pothole detector using RCNN

5. Building your road pothole detector using YOLO

6. Building you road pothole detector using Tensorflow object detection API

7. Building your video analytics application for detecting potholes

8. Deploying your video analytics application for detection of potholes

In this post we build a custom object detector from scratch progressively using different methods like pyramid segmentation, sliding window and non maxima suppression. These methods are legacy methods which lays the foundation to many of the modern object detection methods. Let us look at the processes which will be covered in building an object detector from scratch.

  1. Prepare the train and test sets from the annotated images ( Covered in the last post)
  2. Build a classifier for detecting potholes
  3. Build the inference pipeline using image pyramids and sliding window techniques to predict bounding boxes for potholes
  4. Optimise the bounding boxes using Non Maxima suppression.

We will be covering all the topics from step 2 in this post. These posts are heavily inspired by the following posts.

Let us dive in.

Training a classifier on the data

In the last post we prepared our training data from positive and negative examples and then saved the data in h5py format. In this post we will use that data to build our pothole classifier. The classifier we will be building is a binary classifier which has a positive class and a negative class. We will be training this classifier using a SVM model. The choice of SVM model is based on some earlier work which is done in this space, however I would urge you to experiment with other classification models as well.

We will start off from where we stopped in the last section. We will read the database from disk and extract the labels and data

# Read the data base from disk
db = h5py.File(outputPath, "r")
# Extract the labels and data
(labels, data) = (db["pothole_features_all"][:, 0], db["pothole_features_all"][:, 1:])
# Close the data base
db.close()

print(labels.shape)
print(data.shape)

We will now use the data and labels to build the classifier

# Build the SVM model
model = SVC(kernel="linear", C=0.01, probability=True, random_state=123)
model.fit(data, labels)

Once the model is fit we will save the model as a pickle file in the output folder.

# Save the model in the output folder
modelPath = 'data/models/model.cpickle'
f = open(modelPath, "wb")
f.write(pickle.dumps(model))
f.close()

Please remember to create the 'models' folder in your local drive in the 'data' folder before saving the model. Once the model is saved you will be able to see the model pickle file within the path you specified.

Now that we have build the classifier, we will use this classifier for object detection in the next section. We will be covering two important concepts in the next section which is important for object detection, Image pyramids and Sliding windows. Let us get familiar with those concepts first.

Image Pyramids and Sliding window techniques

Let us try to understand the concept of image pyramids with an example. Let us assume that we have a window of fixed size and potholes are detected only if they fit perfectly inside the window. Let us look at how well the potholes are detected when using a fixed size window. Take the case of layer1 of the image below. We can see that the fixed sized window was able to detect one of the potholes which was further down the road as it fit well within the window size, however the bigger pothole which is at the near end the image is not detected because the window was obviously smaller than size of the pothole.

As a way to solve this, let us progressively reduce the size of the image, and try to fit the potholes to the fixed window size, as shown in the figure below. With the reduction in size of the image, the object we want to detect also reduces in size. Since our detection window remains the same, we are able to detect more potholes including the biggest one, when the image sizes are reduced. Thereby we will be able to detect most of the potholes which otherwise would not have been possible with a fixed size window and a constant size image. This is the concept behind image pyramids.

The name image pyramids signifies the fact that, if the scaled images are stacked vertically, then it will fit inside a pyramid as shown in the below figure.

The implementation of image pyramids can be done easily using Sklearn. There are many different types of image pyramid implementation. Some of the prominent ones are Gaussian pyramids and Laplacian pyramids. You can read about these pyramids in the link give here. Let us quickly look at the implementation of of pyramids.

from skimage.transform import pyramid_gaussian
for imgPath in allFiles[-2:-1]:
    # Read the image
    image = cv2.imread(imgPath)
    # loop over the layers of the image pyramid and display them
    for (i, layer) in enumerate(pyramid_gaussian(image, downscale=1.2)):
        # Break the loop if the image size is less than our window size
        if layer.shape[1] < 80 or layer.shape[0] < 40:
            break
        print(layer.shape)

From the output we can see how the images are scaled down progressively.

Having see the image pyramids, its time to discuss about sliding window. Sliding windows are effective methods to identify objects in an image at various scales and locations. As the name suggests, this method involves a window of standard length and width which slides accross an image to extract features. These features will be used in a classifier to identify object of interest. Let us look at the code block below to understand the dynamics of the sliding window method.

# Read the image
image = cv2.imread(allFiles[-2])
# Define the window size
windowSize = [80,40]
# Define the step size
stepSize = 40
# slide a window across the image
for y in range(0, image.shape[0], stepSize):
    for x in range(0, image.shape[1], stepSize):
        # Clone the image
        clone = image.copy()
        # Draw a rectangle on the image
        cv2.rectangle(clone, (x, y), (x + windowSize[0], y + windowSize[1]), (0, 255, 0), 2)
        plt.imshow()

To implement the sliding window we need to understand some of the parameters which are used. The first is the window size, which is the dimension of the fixed window we would be sliding accross the image. We earlier calculated the size of this window to be [80,40] which was the average size of a pothole in our distribution. The second parameter is the step size. A step size is the number of pixels we need to step to move the fixed window accross the image. Smaller the step size, we will have to move through more pixels and vice-versa. We dont want to slide through every pixel and definitely dont want to skip important features, and therefore the step size is a necessary parameter. An ideal step size would depend on the image size. For our case let us experiment with the ‘y’ cordinate size of our fixed window which is 40. I would encourage to experiment with different step sizes and observe the results before finalising the step size.

To implement this method, we first iterates through the vertical distance starting from 0 to the height of the image with increments of the stepsize. We have an inner iterative loop which loops through the horizontal direction ranging from 0 to the width of the image with increments of stepsize. For each of these iterations we capture the x and y cordinates and then extract a rectangle with the same shape of the fixed window size. In the above implementation we are only drawing a rectangle on the image to understand the dynamics. However when we implement this along with image pyramids, we will crop an image size with the dimension of the window size as we slide accross the image. Let us see some of the sample outputs of the sliding window.

From the above output we can see how the fixed window slides accross the image both horizontally and vertically with a step size to extract features from the image of the same size as the fixed window.

So far we have seen the pyramid and the sliding window implementations independently. These two methods have to be integrated to use it as an object detector. However for integrating them we need to convert the sliding window method into a function. Let us look at the function to implement sliding windows.

# Function to implement sliding window
def slidingWindow(image, stepSize, windowSize):
    # slide a window across the image
    for y in range(0, image.shape[0], stepSize):
        for x in range(0, image.shape[1], stepSize):
            # yield the current window
            yield (x, y, image[y:y + windowSize[1], x:x + windowSize[0]])

The function is not very different from what we implemented earlier. The only difference is as the output we yield a tuple of the x,y cordinates and the crop of the image of the same size as the window Size. Next we will see how we integrate this function with the image pyramids to implement our custom object detector.

Building the object detector

Its now time to bring all what we defined into creating our object detector. As a first step let us load the model which we saved during the training phase

# Listing the path were we stored the model
modelPath = 'data/models/model.cpickle'
# Loading the model we trained earlier
model = pickle.loads(open(modelPath, "rb").read())
model

Now let us look at the complete code to implement our object detector

# Initialise lists to store the bounding boxes and probabilities
boxes = []
probs = []
# Define the HOG parameters
orientations=12
pixelsPerCell=(4, 4)
cellsPerBlock=(2, 2)
# Define the fixed window size
windowSize=(80,40)
# Pick a random image from the image path to check our prediction
imgPath = sample(allFiles,1)[0]
# Read the image
image = cv2.imread(imgPath)
# Converting the image to grayscale
gray = cv2.cvtColor(image, cv2.COLOR_BGR2GRAY)
# loop over the image pyramid
for (i, layer) in enumerate(pyramid_gaussian(image, downscale=1.2)):
    # Identify the current scale of the image
    scale = gray.shape[0] / float(layer.shape[0])
    # loop over the sliding window for each layer of the pyramid
    for (x, y, window) in slidingWindow(layer, stepSize=40, windowSize=(80,40)):
        # if the current window does not meet our desired window size, ignore it
        if window.shape[0] != windowSize[1] or window.shape[1] != windowSize[0]:
            continue
        # Let us now extract the hog features of this window within the image
        feat = hogFeatures(window,orientations,pixelsPerCell,cellsPerBlock,normalize=True).reshape(1,-1)
        # Get the prediction probabilities for the positive class ( potholesf)
        prob = model.predict_proba(feat)[0][1]

        # Check if the probability is greater than a threshold probability
        if prob > 0.95:
            # Extract (x, y)-coordinates of the bounding box using the current scale
            # Starting coordinates
            (startX, startY) = (int(scale * x), int(scale * y))
            # Ending coordinates
            endX = int(startX + (scale * windowSize[0]))
            endY = int(startY + (scale * windowSize[1]))
            # update the list of bounding boxes and probabilities
            boxes.append((startX, startY, endX, endY))
            probs.append(prob)

# loop over the bounding boxes and draw them
for (startX, startY, endX, endY) in boxes:
    cv2.rectangle(image, (startX, startY), (endX, endY), (0, 0, 255), 2)

plt.imshow(image,aspect='equal')
plt.show()

To start of we initialise two lists in lines 2-3 where we will store the bounding box coordinates and also the probabilities which indicates the confidence about detecting potholes in the image.

We also define some important parameters which are required for HOG feature extraction method in lines 5-7

  1. orientations
  2. pixels per Cell
  3. Cells per block

We also define the size of our fixed window in line 9

To test our process, we randomly sample an image from the list of images we have and then convert the image into gray scale in lines 11-15.

We then start the iterative loop to implement the image pyramids in line 17. For each iteration the input image is scaled down as per the scaling factor we defined.Next we calculate the running scale of the image in line 19. The scale would always be the original shape divided by the scaled down image. We need to find the scale to blow up the x,y coordinates to the orginal size of the image later on.

Next we start the sliding window implementation in line 21. We provide the scaled down version of the image as the input along with the stepSize and the window size. The step size is the parameter which indicates by how much the window has to slide accross the original image. The window size indicates the size of the sliding window. We saw the mechanics of these when we looked at the sliding window function.

In lines 23-24 we ensure that we only take images, which meets our minimum size specification.For any image which passes the minimum size specification, HOG features are extracted in line 26. On the extracted HOG features, we do a prediction in line 28. The prediction gives the probability whether the image is a pothole or not. We extract only probability of the positive class. We then take only those images were the probability is greater than a threshold we have defined in line 31. We give a high threshold because, our distribution of both the positive and negative images are very similar. So to ensure that we get only the potholes, we given a higher threshold. The threshold has been arrived at after fair bit of experimentation. I would encourage you to try out with different thresholds before finalising the threshold you want.

Once we get the predictions, we take those x and y cordinates and then blow it to the original size using the scale we earlier calculated in lines 34-37. We find the starting cordinates and the ending cordinates and then append those coordinates in the lists we defined, in lines 39-40.

In lines 43-47, we loop through each of the coordinates and draw bounding boxes around the image.

Let us look at the output we have got, we can see that there are multiple bounding boxes created around the area were there are potholes. We can be happy that the object detector is doing its job by localising around the area around a pothole in most of the cases. However there are examples where the detector has detected objects other than potholes. We will come to that issue later. Let us first address another important issue.

All the images have multiple overlapping bounding boxes. Having a lot of bounding boxes can sometimes be cumbersome say if we want to calculate the area where the pot hole is present. We need to find a way to reduce the number of overlapping bounding boxes. This is were we use a technique called Non Maxima suppression. The objective of Non maxima suppression is to combine bounding boxes with significant overalp and get a single bounding box. The method which we would be implementing is inspired from this post

Non Maxima Suppression

We would be implementing a customised method of the non maxima suppression implementation. We will be implementing it through a function.

def maxOverlap(boxes):
    '''
    boxes : This is the cordinates of the boxes which have the object
    returns : A list of boxes which do not have much overlap
    '''
    # Convert the bounding boxes into an array
    boxes = np.array(boxes)
    # Initialise a box to pick the ids of the selected boxes and include the largest box
    selected = []
    # Continue the loop till the number of ids remaining in the box is greater than 1
    while len(boxes) > 1:
        # First calculate the area of the bounding boxes
        x1 = boxes[:, 0]
        y1 = boxes[:, 1]
        x2 = boxes[:, 2]
        y2 = boxes[:, 3]
        area = (x2 - x1) * (y2 - y1)
        # Sort the bounding boxes based on its area
        ids = np.argsort(area)
        #print('ids',ids)
        # Take the coordinates of the box with the largest area
        lx1 = boxes[ids[-1], 0]
        ly1 = boxes[ids[-1], 1]
        lx2 = boxes[ids[-1], 2]
        ly2 = boxes[ids[-1], 3]
        # Include the largest box into the selected list
        selected.append(boxes[ids[-1]].tolist())
        # Initialise a list for getting those ids that needs to be removed.
        remove = []
        remove.append(ids[-1])
        # We loop through each of the other boxes and find the overlap of the boxes with the largest box
        for id in ids[:-1]:
            #print('id',id)
            # The maximum of the starting x cordinate is where the overlap along width starts
            ox1 = np.maximum(lx1, boxes[id,0])
            # The maximum of the starting y cordinate is where the overlap along height starts
            oy1 = np.maximum(ly1, boxes[id,1])
            # The minimum of the ending x cordinate is where the overlap along width ends
            ox2 = np.minimum(lx2, boxes[id,2])
            # The minimum of the ending y cordinate is where the overlap along height ends
            oy2 = np.minimum(ly2, boxes[id,3])
            # Find area of the overlapping coordinates
            oa = (ox2 - ox1) * (oy2 - oy1)
            # Find the ratio of overlapping area of the smaller box with respect to its original area
            olRatio = oa/area[id]
            # If the overlap is greater than threshold include the id in the remove list
            if olRatio > 0.50:
                remove.append(id)
        # Remove those ids from the original boxes
        boxes = np.delete(boxes, remove,axis = 0)
        # Break the while loop if nothing to remove
        if len(remove) == 0:
            break
    # Append the remaining boxes to the selected
    for i in range(len(boxes)):
        selected.append(boxes[i].tolist())
    return np.array(selected)

The input to the function are the bounding boxes we got after our prediction. Let me give a big picture of what this implementation is all about. In this implementation we start with the box with the largest area and progressively eliminate boxes which have considerable overlap with the largest box. We then take the remaining boxes after elimination and the repeat the process of elimination till we get to the minimum number of boxes. Let us now see this implementation in the code above.

In line 7, we convert the bounding boxes into an numpy array and the initialise a list to store the bounding boxes we want to return in line 9.

Next in line 11, we start the continues loop for elimination of the boxes till the number of boxes which remain is less than 2.

In lines 13-17, we calculate the area of all the bounding boxes and then sort them in ascending order in line 19.

We then take the cordinates of the box with the largest area in lines 22-25 and then append the largest box to the selection list in line 27. We initialise a new list for the boxes which needs to be removed and then include the largest box in the removal list in line 30.

We then start another iterative loop to find the overlap of the other bounding boxes with the largest box in line 32. In lines 35-43, we find the coordinates of the overlapping portion of each of the other boxes with the largest box and the take the area of the overlapping portion. In line 45 we find the ratio of the overlapping area to the original area of the bounding box which we iterate through. If the ratio is larger than a threshold value, we include that box to the removal list in lines 47-48 as this has good overlap with the largest box. After iterating through all the boxes in the list, we will get a list of boxes which has good overlap with the largest box. We then remove all those overlapping boxes and the current largest box from the original list of boxes in line 50. We continue this process till there are no more boxes to be removed. Finally we add the last remaining box to the selected list and then return the selection.

Let us implement this function and observe the result

# Get the selected list
selected = maxOverlap(boxes)

Now let us look at different examples after non maxima suppression.

# Get the image again
image = cv2.imread(imgPath)
# Make a copy of the image
clone = image.copy()
for (startX, startY, endX, endY) in selected:
    cv2.rectangle(clone, (startX, startY), (endX, endY), (0, 255, 0), 2)

plt.imshow(clone,aspect='equal')
plt.show()
Non maxima suppression

We can see that the bounding boxes are considerably reduced using our non maxima suppression implementation.

Improvement Opportunities

Eventhough we have got reasonable detection effectiveness, is the model we built perfect ? Absolutely not. Let us look at some of the major pitfalls

Misclassifications of objects :

From the outputs, we can see that we have misclassified some of the objects.

Most of the misclassifications we have seen are for vegetation. There are also cases were road signs are also misclassified as potholes.

A major reason we have mis classification is because our training data is limited. We used only 19 positive images and 20 negative examples. Which is a very small data set for tasks like this. Considering the fact that the data set is limited the classifier has done a decent job. Also for negative images, we need to include some more variety, like get some road signs, vehicles, vegetation etc labelled as negative images. So with more positive images and more negative images with little more variety of objects that are likely to be found on roads will improve the classification accuracy of the classifier.

Another strategy is to experiment with different types of classifiers. In our example we used a SVM classifier. It would be worthwhile to use other binary classifiers starting from Logistic regression, Naive Bayes, Random forest, XG boost etc. I would encourage you to try out with different classifiers and then verify the results.

Non detection of positive classes

Along with misclassifications, we have also seen non detection of positive classes.

As seen from the examples, we can see that there has been non detection in cases of potholes with water in it. In addition some of the potholes which are further along the road are not detected.

These problems again can be corrected by including more variety in the positive images, by including potholes with water in it. It will also help to include images with potholes further away along the road. The other solution is to preprocess images with different techniques like smoothing and blurring, thresholding, gradient and edge detection, contours, histograms etc. These methods will help in highliging the areas with potholes which will help in better detection. In addition, increasing the number of positive examples will also help in addressing the problems associated with non detection.

What Next ?

The idea behind this post was to give you a perspective in building an object detector from scratch. This was also an attempt to give an experience in working in cases where the data sets are limited and where you have to create the necessary data sets. I believe these exercises will equip you will capabilities to deal with such issues in your projects.

Now that you have seen the basic grounds up approach, it is time to use this experience to learn more state of the art techniques. In the next post we will start with more advanced techniques. We will also be using transfer learning techniques extensively from the next post. In the next post we will cover object detection using RCNN.

To be notified of the next post please subscribe to this blog post .You can also subscribe to our Youtube channel for all the videos related to this series.

You can also access the code base for this series from the following git hub link

Do you want to Climb the Machine Learning Knowledge Pyramid ?

Knowledge acquisition is such a liberating experience. The more you invest in your knowledge enhacement, the more empowered you become. The best way to acquire knowledge is by practical application or learn by doing. If you are inspired by the prospect of being empowerd by practical knowledge in Machine learning, subscribe to our Youtube channel

I would also recommend two books I have co-authored. The first one is specialised in deep learning with practical hands on exercises and interactive video and audio aids for learning

This book is accessible using the following links

The Deep Learning Workshop on Amazon

The Deep Learning Workshop on Packt

The second book equips you with practical machine learning skill sets. The pedagogy is through practical interactive exercises and activities.

The Data Science Workshop Book

This book can be accessed using the following links

The Data Science Workshop on Amazon

The Data Science Workshop on Packt

Enjoy your learning experience and be empowered !!!!

Building Self Learning Recommendation system – VIII : Evaluating deployment options

This is the eighth and last post of our series on building a self learning recommendation system using reinforcement learning. This series consists of 8 posts where in we progressively build a self learning recommendation system.

  1. Recommendation system and reinforcement learning primer
  2. Introduction to multi armed bandit problem
  3. Self learning recommendation system as a K-armed bandit
  4. Build the prototype of the self learning recommendation system : Part I
  5. Build the prototype of the self learning recommendation system : Part II
  6. Productionising the self learning recommendation system : Part I – Customer Segmentation
  7. Productionising self learning recommendation system: Part II : Implementing self learning recommendations
  8. Evaluating deployment options for the self learning recommendation systems. ( This post )

This post ties together all what we discussed in the previous two posts where in we explored all the classes and methods we built for the application. In this post we will implement the driver file which controls all the processes and then explore different options to deploy this application.

Implementing the driver file

Now that we have seen all the classes and methods of the application, let us now see the main driver file which will control the whole process.

Open a new file and name it rlRecoMain.py and copy the following code into the file

import argparse
import pandas as pd
from utils import Conf,helperFunctions
from Data import DataProcessor
from processes import rfmMaker,rlLearn,rlRecomend
import os.path
from pymongo import MongoClient

# Construct the argument parser and parse the arguments
ap = argparse.ArgumentParser()
ap.add_argument('-c','--conf',required=True,help='Path to the configuration file')
args = vars(ap.parse_args())

# Load the configuration file
conf = Conf(args['conf'])

print("[INFO] loading the raw files")
dl = DataProcessor(conf)

# Check if custDetails already exists. If not create it
if os.path.exists(conf["custDetails"]):
    print("[INFO] Loading customer details from pickle file")
    # Load the data from the pickle file
    custDetails = helperFunctions.load_files(conf["custDetails"])
else:
    print("[INFO] Creating customer details from csv file")
    # Let us load the customer Details
    custDetails = dl.gvCreator()
    # Starting the RFM segmentation process
    rfm = rfmMaker(custDetails,conf)
    custDetails = rfm.segmenter()
    # Save the custDetails file as a pickle file
    helperFunctions.save_clean_data(custDetails,conf["custDetails"])

# Starting the self learning Recommendation system

# Check if the collections exist in Mongo DB
client = MongoClient(port=27017)
db = client.rlRecomendation

# Get all the collections from MongoDB
countCol = db["rlQuantdic"]
polCol = db["rlValuedic"]
rewCol = db["rlRewarddic"]
recoCountCol = db['rlRecotrack']

print(countCol.estimated_document_count())

# If Collections do not exist then create the collections in MongoDB
if countCol.estimated_document_count() == 0:
    print("[INFO] Main dictionaries empty")
    rll = rlLearn(custDetails, conf)
    # Consolidate all the products
    rll.prodConsolidator()
    print("[INFO] completed the product consolidation phase")
    # Get all the collections from MongoDB
    countCol = db["rlQuantdic"]
    polCol = db["rlValuedic"]
    rewCol = db["rlRewarddic"]

# start the recommendation phase
rlr = rlRecomend(custDetails,conf)
# Sample a state since the state is not available
stateId = rlr.stateSample()
print(stateId)

# Get the respective dictionaries from the collections

countDic = countCol.find_one({stateId: {'$exists': True}})
polDic = polCol.find_one({stateId: {'$exists': True}})
rewDic = rewCol.find_one({stateId: {'$exists': True}})

# The count dictionaries can exist but still recommendation dictionary can not exist. So we need to take this seperately

if recoCountCol.estimated_document_count() == 0:
    print("[INFO] Recommendation tracking dictionary empty")
    recoCountdic = {}
else:
    # Get the dictionary from the collection
    recoCountdic = recoCountCol.find_one({stateId: {'$exists': True}})


print('recommendation count dic', recoCountdic)


# Initialise the Collection checker method
rlr.collfinder(stateId,countDic,polDic,rewDic,recoCountdic)
# Get the list of recommended products
seg_products = rlr.rlRecommender()
print(seg_products)
# Initiate customer actions

click_list,buy_list = rlr.custAction(seg_products)
print('click_list',click_list)
print('buy_list',buy_list)

# Get the reward functions for the customer action
rlr.rewardUpdater(seg_products,buy_list ,click_list)

We import all the necessary libraries and classes in lines 1-7.

Lines 10-12, detail the argument parser process. We provide the path to our configuration file as the argument. We discussed in detail about the configuration file in post 6 of this series. Once the path of the configuration file is passed as the argument, we read the configuration file and the load the value in the variable conf in line 15.

The first of the processes is to initialise the dataProcessor class in line 18. As you know from post 6, this class has the methods for loading and processing data. After this step, lines 21-33 implements the raw data loading and processing steps.

In line 21 we check if the processed data frame custDetails is already present in the output directory. If it is present we load it from the folder in line 24. If we havent created the custDetails data frame before, we initiate that action in line 28 using the gvCreator method we have seen earlier. In lines 30-31, we create the segments for the data using the segmenter method in the rfmMaker class. Finally the custDetails data frame is saved as a pickle file in line 33.

Once the segmentation process is complete the next step is to start the recommendation process. We first establish the connection with our collection in lines 38-39. Then we collect the 4 collections from MongoDB in lines 42-45. If the collections do not exist it will return a ‘None’.

If the collections are none, we need to create the collections. This is done in lines 50-59. We instantiate the rlLearn class in line 52 and the execute the prodConsolidator() method in line 54. Once this method is run the collections would be created. Please refer to the prodConsolidator() method in post 7 for details. Once the collections are created, we get those collections in lines 57-59.

Next we instantiate the rlRecomend class in line 62 and then sample a stateID in line 64. Please note that the sampling of state ID is only a work around to simulate a state in the absence of real customer data. If we were to have a live application, then the state Id would be created each time a customer logs into the sytem to buy products. As you know the state Id is a combination of the customers segment, month and day in which the logging happens. So as there are no live customers we are simulating the stateId for our online recommendation process.

Once we have sampled the stateId, we need to extract the dictionaries corresponding to that stateId from the MongoDb collections. We do that in lines 69-71. We extract the dictionary corresponding to the recommendation as a seperate step in lines 75-80.

Once all the dictionaries are extracted, we do the initialisation of the dictionaries in line 87 using the collfinder method we explored in post 7 . Once the dictionaries are initialised we initiate the recommendation process in line 89 to get the list of recommended products.

Once we get the recommended products we simulate customer actions in line 93, and then finally update the rewards and values using rewardUpdater method in line 98.

This takes us to the end of the complete process to build the online recommendation process. Let us now see how this application can be run on the terminal

Figure 1 : Running the application on terminal

The application can be executed on the terminal with the below command

$ python rlRecoMain.py --conf config/custprof.json

The argument we give is the path to the configuration file. Please note that we need to change directory to the rlreco directory to run this code. The output from the implementation would be as below

The data can be seen in the MongoDB collections also. Let us look at ways to find the data in MongoDB collections.

To initialise Mongo db from terminal, use the following command

Figure 3 : Initialize Mongo

You should get the following output

Now to find all the data bases in Mongo DB you can use the below command

You will be able to see all the databases which you have created. The one marked in red is the database we created. No to use that data base the command used is use rlRecomendation as shown below. We will get the command that the database has been switched to the desired data base.

To see all the collections we have made in this database we can use the below command.

From the output we can see all the collections we have created. Now to see some specific record within the collections, we can use the following command.

db.rlValuedic.find({"Q1_August_1_Monday":{$exists:true} })

In the above command we are trying to find all records in the collection rlValuedic for the stateID "Q1_August_1_Monday". Once we execute this command we get all the records in this collection for this specific stateID. You should get the below output.

The output displays all the proucts for that stateID and its value function.

What we have implemented in code is a simulation of the complete process. To run this continuously for multiple customers, we can create another scrip with a list of desired customers and then execute the code multiple times. I will leave that step as an exercise for you to implement. Now let us look at different options to deploy this application.

Deployment of application

The end product of any data science endeavour should be to build an application and sharing it with the world. There are different options to deploy python applications. Let us look at some of the options available. I would encourage you to explore more methods and share your results.

Flask application with Heroku

A great option to deploy your applications is to package it as a Flask application and then deploy it using Heroku. We have discussed this option in one of our earlier series, where we built a machine translation application. You can refer this link for details. In this section we will discuss the nuances of building the application in Flask and then deploying it on Heroku. I will leave the implementation of the steps for you as an exercise.

When deploying the self learning recommendation system we have built, the first thing which we need to design is what the front end will contain. From the perspective of the processes we have implemented, we need to have the following processes controlled using the front end.

  1. Training process : This is the process which takes the raw data, preprocesses the data and then initialises all the dictionaries. This includes all the processes till line 59 in the driver file rlRecoMain.py. We need to initialise the process of training from the front end of the flask application. In the background all the process till line 59 should run and the dictionaries needs to be updated.
  2. Recommendation simulation : The second process which needs to be controlled is the one where we get the recommendations. The start of this process is the simulation of the state from the front end. To do this we can provide a drop down of all the customer IDs on the flask front end and take the system time details to form the stateID. Once this stateID is generated, we start the recommendation process which includes all the process starting from line 62 till line 90 in the the driver file rlRecoMain.py. Please note that line 64 is the stateID simulating process which will be controlled from the front end. So that line need not be implemented. The final output, which is the list of all recommended products needs to be displayed on the front end. It will be good to add some visual images along with the product for visual impact.
  3. Customer action simulation : Once the recommended products are displayed on the front end, we can send feed back from the front end in terms of the products clicked and the products bought through some widgets created in the front end. These widgets will take the place of line 93, in our implementation. These feed back from the front end needs to be collected as lists, which will take the place of click_list and buy_list given in lines 94-95. Once the customer actions are generated, the back end process in line 98, will have to kick in to update the dictionaries. Once the cycle is completed we can build a refresh button on the screen to simulate the recommendation process again.

Once these processes are implemented using a Flask application, the application can be deployed on Heroku. This post will give you overall guide into deploying the application on Heroku.

These are broad guidelines for building the application and then deploying them. These need not be the most efficient and effective ones. I would challenge each one of you to implement much better processes for deployment. Request you to share your implementations in the comments section below.

Other options for deployment

So far we have seen one of the option to build the application using Flask and then deploy them using Heroku. There are other options too for deployment. Some of the noteable ones are the following

  • Flask application on Ubuntu server
  • Flask application on Docker

The attached link is a great resource to learn about such deployment. I would challenge all of you to deploy using any of these implementation steps and share the implementation for the community to benefit.

Wrapping up.

This is the last post of the series and we hope that this series was informative.

We will start a new series in the near future. The next series will be on a specific problem on computer vision specifically on Object detection. In the next series we will be building a ‘Road pothole detector using different object detection algorithms. This series will touch upon different methods in object detection like Image Pyramids, RCNN, Yolo, Tensorflow Object detection API etc. Watch out this space for the next series.

Please subscribe to this blog post to get notifications when the next post is published.

You can also subscribe to our Youtube channel for all the videos related to this series.

The complete code base for the series is in the Bayesian Quest Git hub repository

Do you want to Climb the Machine Learning Knowledge Pyramid ?

Knowledge acquisition is such a liberating experience. The more you invest in your knowledge enhacement, the more empowered you become. The best way to acquire knowledge is by practical application or learn by doing. If you are inspired by the prospect of being empowerd by practical knowledge in Machine learning, subscribe to our Youtube channel

I would also recommend two books I have co-authored. The first one is specialised in deep learning with practical hands on exercises and interactive video and audio aids for learning

This book is accessible using the following links

The Deep Learning Workshop on Amazon

The Deep Learning Workshop on Packt

The second book equips you with practical machine learning skill sets. The pedagogy is through practical interactive exercises and activities.

The Data Science Workshop Book

This book can be accessed using the following links

The Data Science Workshop on Amazon

The Data Science Workshop on Packt

Enjoy your learning experience and be empowered !!!!

Building Self Learning Recommendation system – VII : Productionizing the application : II

This is the seventh post of our series on building a self learning recommendation system using reinforcement learning. This series consists of 8 posts where in we progressively build a self learning recommendation system.

  1. Recommendation system and reinforcement learning primer
  2. Introduction to multi armed bandit problem
  3. Self learning recommendation system as a K-armed bandit
  4. Build the prototype of the self learning recommendation system : Part I
  5. Build the prototype of the self learning recommendation system : Part II
  6. Productionising the self learning recommendation system : Part I – Customer Segmentation
  7. Productionising the self learning recommendation system: Part II – Implementing self learning recommendation ( This Post )
  8. Evaluating different deployment options for the self learning recommendation systems.

This post builds on the previous post where we started off with productionizing the application using python scripts. In the last post we completed the customer segmentation part. In this post we continue from where we left off and then build the self learning system using python scripts. Let us get going.

Creation of States

Let us take a quick recap of the project structure and what we covered in the last post.

In the last post we were in the early part of our main driver file rlRecoMain.py. We explored rfmMaker class in file rfmProcess.py from the processes directory. We will now explore selfLearnProcess.py file in the same directory.

Open a new file and name it selfLearnProcess.py and insert the following code

import pandas as pd
from numpy.random import normal as GaussianDistribution
from collections import OrderedDict
from collections import Counter
import operator
from random import sample
import numpy as np
from pymongo import MongoClient
client = MongoClient(port=27017)
db = client.rlRecomendation



class rlLearn:
    def __init__(self,custDetails,conf):
        # Get the date  as a seperate column
        custDetails['Date'] = custDetails['Parse_date'].apply(lambda x: x.strftime("%d"))
        # Converting date to float for easy comparison
        custDetails['Date'] = custDetails['Date'].astype('float64')
        # Get the period of month column
        custDetails['monthPeriod'] = custDetails['Date'].apply(lambda x: int(x > conf['monthPer']))
        # Aggregate the custDetails to get a distribution of rewards
        rewardFull = custDetails.groupby(['Segment', 'Month', 'monthPeriod', 'Day', conf['product_id']])[conf['prod_qnty']].agg(
            'sum').reset_index()
        # Get these data frames for all methods
        self.custDetails = custDetails
        self.conf = conf
        self.rewardFull = rewardFull
        # Defining some dictionaries for storing the values
        self.countDic = {}  # Dictionary to store the count of products
        self.polDic = {}  # Dictionary to store the value distribution
        self.rewDic = {}  # Dictionary to store the reward distribution
        self.recoCountdic = {}  # Dictionary to store the recommendation counts

    # Method to find unique values of each of the variables
    def uniqeVars(self):
        # Finding unique value for each of the variables
        segments = list(self.rewardFull.Segment.unique())
        months = list(self.rewardFull.Month.unique())
        monthPeriod = list(self.rewardFull.monthPeriod.unique())
        days = list(self.rewardFull.Day.unique())
        return segments,months,monthPeriod,days

    # Method to consolidate all products
    def prodConsolidator(self):
        # Get all the unique values of the variables
        segments, months, monthPeriod, days = self.uniqeVars()
        # Creating the consolidated dictionary
        for seg in segments:
            for mon in months:
                for period in monthPeriod:
                    for day in days:
                        # Get the subset of the data
                        subset1 = self.rewardFull[(self.rewardFull['Segment'] == seg) & (self.rewardFull['Month'] == mon) & (
                                self.rewardFull['monthPeriod'] == period) & (self.rewardFull['Day'] == day)]
                        # INitializing a temporary dictionary to storing in mongodb
                        tempDic = {}
                        # Check if the subset is valid
                        if len(subset1) > 0:
                            # Iterate through each of the subset and get the products and its quantities
                            stateId = str(seg) + '_' + mon + '_' + str(period) + '_' + day
                            # Define a dictionary for the state ID
                            self.countDic[stateId] = {}
                            tempDic[stateId] = {}
                            for i in range(len(subset1.StockCode)):
                                # Store in the Count dictionary
                                self.countDic[stateId][subset1.iloc[i]['StockCode']] = int(subset1.iloc[i]['Quantity'])
                                tempDic[stateId][subset1.iloc[i]['StockCode']] = int(subset1.iloc[i]['Quantity'])
                            # Dumping each record into mongo db
                            db.rlQuantdic.insert(tempDic)

        # Consolidate the rewards and value functions based on the quantities
        for key in self.countDic.keys():
            # Creating two temporary dictionaries for loading in Mongodb
            tempDicpol = {}
            tempDicrew = {}
            # First get the dictionary of products for a state
            prodCounts = self.countDic[key]
            self.polDic[key] = {}
            self.rewDic[key] = {}
            # Initializing temporary dictionaries also
            tempDicpol[key] = {}
            tempDicrew[key] = {}
            # Update the policy values
            for pkey in prodCounts.keys():
                # Creating the value dictionary using a Gaussian process
                self.polDic[key][pkey] = GaussianDistribution(loc=prodCounts[pkey], scale=1, size=1)[0].round(2)
                tempDicpol[key][pkey] = self.polDic[key][pkey]
                # Creating a reward dictionary using a Gaussian process
                self.rewDic[key][pkey] = GaussianDistribution(loc=prodCounts[pkey], scale=1, size=1)[0].round(2)
                tempDicrew[key][pkey] = self.rewDic[key][pkey]
            # Dumping each of these in mongo db
            db.rlRewarddic.insert(tempDicrew)
            db.rlValuedic.insert(tempDicpol)
        print('[INFO] Dumped the quantity dictionary,policy and rewards in MongoDB')

As usual we start with import of the libraries we want from lines 1-7. In this implementation we make a small deviation from the prototype which we developed in the previous post. During the prototyping phase we predominantly relied on dictionaries to store data. However here we would be storing data in Mongo DB. Those of you who are not fully conversant with MongoDB can refer to some good tutorials on MongDB like the one here. I will also be explaining the key features as and when required. In line 8, we import the MongoClient which is required for connections with the data base. We then define the client using the default port number ( 27017 ) in line 9 and then name the data base where we will store the recommendation in line 10. The name of the database we have selected is rlRecomendation . You are free to choose any name of your choice.

Let us now explore the rlLearn class. The constructor of the class which starts from line 15, takes the custDetails data frame and the configuration file as inputs. You would already be familiar with lines 17-23 from our prototyping phase, where we extract information to create states and then consolidate the data frame to get the quantities of each state. In lines 30-33, we create dictionaries where we store the relevant information like count of products, value distribution, reward distribution and the number of times the products are recommended.

The main method within the rlLearn class is the prodConslidator() method in lines 45-95. We have seen the details of this method in the prototyping phase. Just to recap, in this method we iterate through each of the components of our states and then store the quantities of each product under the state in the dictionaries. However there is a subtle difference from what we did during the prototyping phase. Here we are inserting each state and its associated products in Mongodb data base we created, as shown in line 70, 93 and 94. We create a temporary dictionary in line 57 to dump each state into Mongodb. We also store the data in the dictionaries,as we did during the prototyping phase, so that we get the data for other methods in this class. The final outcome from this method, is the creation of the count dictionary, value dictionary and reward dictionary from our data and updation of this data in Mongodb.

This takes us to the end of the rlLearn class.

We now go back to the driver file rlRecoMain.py and the explore the next important class rlRecomend.

The rlRecomend class has the methods which are required for recommending products. This class has many methods and therefore we will go one by one through each of the methods. We have seen all these methods during the prototyping phase and therefore we will not get into detailed explanation of these methods here. For detailed explanation you can refer to the previous post.

Now on the selfLearnProcess.py start adding the code pertaining to the rlRecomend class.

class rlRecomend:
    def __init__(self, custDetails, conf):
        # Get the date  as a seperate column
        custDetails['Date'] = custDetails['Parse_date'].apply(lambda x: x.strftime("%d"))
        # Converting date to float for easy comparison
        custDetails['Date'] = custDetails['Date'].astype('float64')
        # Get the period of month column
        custDetails['monthPeriod'] = custDetails['Date'].apply(lambda x: int(x > conf['monthPer']))
        # Aggregate the custDetails to get a distribution of rewards
        rewardFull = custDetails.groupby(['Segment', 'Month', 'monthPeriod', 'Day', conf['product_id']])[
            conf['prod_qnty']].agg(
            'sum').reset_index()
        # Get these data frames for all methods
        self.custDetails = custDetails
        self.conf = conf
        self.rewardFull = rewardFull

The above code is for the constructor of the class ( lines 97 – 112 ), which is similar to the constructor of the rlLearn class. Here we consolidate the custDetails data frame and get the count of each products for the respective state.

Let us now look at the next two methods. Add the following code to the class we earlier created.

# Method to find unique values of each of the variables
    def uniqeVars(self):
        # Finding unique value for each of the variables
        segments = list(self.rewardFull.Segment.unique())
        months = list(self.rewardFull.Month.unique())
        monthPeriod = list(self.rewardFull.monthPeriod.unique())
        days = list(self.rewardFull.Day.unique())
        return segments, months, monthPeriod, days

    # Method to sample a state
    def stateSample(self):
        # Get the unique state elements
        segments, months, monthPeriod, days = self.uniqeVars()
        # Get the context of the customer. For the time being let us randomly select all the states
        seg = sample(segments, 1)[0]  # Sample the segment
        mon = sample(months, 1)[0]  # Sample the month
        monthPer = sample([0, 1], 1)[0]  # sample the month period
        day = sample(days, 1)[0]  # Sample the day
        # Get the state id by combining all these samples
        stateId = str(seg) + '_' + mon + '_' + str(monthPer) + '_' + day
        self.seg = seg
        return stateId

The first method , lines 115 – 121, is to get the unique values of segments, months, month-period and days. This information will be used in some of the methods we will see later on. The second method detailed in lines 124-135, is to sample a state id, through random sampling of the components of a state.

The next methods we will explore are to initialise dictionaries if a state id has not been seen earlier. The first method initialises dictionaries and the second method inserts a recommendation collection record in MongoDB if the state dosent exist. Let us see the code for these methods.

  # Method to initialize a dictionary in case a state Id is not available
    def collfinder(self,stateId,countDic,polDic,rewDic,recoCountdic):
        # Defining some dictionaries for storing the values
        self.countDic = countDic  # Dictionary to store the count of products
        self.polDic = polDic  # Dictionary to store the value distribution
        self.rewDic = rewDic  # Dictionary to store the reward distribution
        self.recoCountdic = recoCountdic  # Dictionary to store the recommendatio
        self.stateId = stateId
        print("[INFO] The current state is :", stateId)
        if self.countDic is None:
            print("[INFO] State ID do not exist")
            self.countDic = {}
            self.countDic[stateId] = {}
            self.polDic = {}
            self.polDic[stateId] = {}
            self.rewDic = {}
            self.rewDic[stateId] = {}
        if self.recoCountdic is None:
            self.recoCountdic = {}
            self.recoCountdic[stateId] = {}
        else:
            self.recoCountdic[stateId] = {}

# Method to update the recommendation dictionary
    def recoCollChecker(self):
        print("[INFO] Inside the recommendation collection")
        recoCol = db.rlRecotrack.find_one({self.stateId: {'$exists': True}})
        if recoCol is None:
            print("[INFO] Inserting the record in the recommendation collection")
            db.rlRecotrack.insert_one({self.stateId: {}})
        return recoCol

The inputs to the first method, as in line 138 are the state Id and all the other 4 dictionaries we extract from Mongo DB, which we will see later on in the main script rlRecoMain.py. If no record exists for a specific state Id, the dictionaries we extract from Mongo DB would be null and therefore we need to initialize these dictionaries for storing all the values of products, its values, rewards and the count of recommendations. The initialisation of these dictionaries are implemented in this method from lines 146-158.

The second initialisation method is to check for the recommendation count dictionary for a specific state Id. We first check for the state Id in the collection in line 163. If the record dosent exist then we insert a blank dictionary for that state in line 166.

Let us now look at the next two methods in the class

    # Create a function to get a list of products for a certain segment
    def segProduct(self,seg, nproducts):
        # Get the list of unique products for each segment
        seg_products = list(self.rewardFull[self.rewardFull['Segment'] == seg]['StockCode'].unique())
        seg_products = sample(seg_products, nproducts)
        return seg_products

    # This is the function to get the top n products based on value
    def sortlist(self,nproducts,seg):
        # Get the top products based on the values and sort them from product with largest value to least
        topProducts = sorted(self.polDic[self.stateId].keys(), key=lambda kv: self.polDic[self.stateId][kv])[-nproducts:][::-1]
        # If the topProducts is less than the required number of products nproducts, sample the delta
        while len(topProducts) < nproducts:
            print("[INFO] top products less than required number of products")
            segProducts = self.segProduct(seg, (nproducts - len(topProducts)))
            newList = topProducts + segProducts
            # Finding unique products
            topProducts = list(OrderedDict.fromkeys(newList))
        return topProducts

The method in lines 171-175 is to sample a list of products for a segment. This method is used incase the number of products in a particular state is less than the total number of products which we want to recommend. In such cases, we randomly sample some products from the list of all products bought by customers in that segment and then add it to the list of products we want to recommend. We will see this in action in sortlist method (lines 178-188).

The sortlist method, sorts the list of products based on the demand for that product and the returns the list of top products. The inputs to this method are the number of products we want to be recommended and the segment ( line 178 ). We then get the top ‘n‘ products by sorting the value dictionary based on the number of times a product is bought as in line 180. If the number of products is less than the required products, sampling of products is done using the segProduct method we saw earlier. The final list of top products is then returned by this method.

The next method which we are going to explore is the one which controls the exploration and exploitation process thereby generating a list of products to be recommended. Let us add the following code to the class.

# This is the function to create the number of products based on exploration and exploitation
    def sampProduct(self,seg, nproducts,epsilon):
        # Initialise an empty list for storing the recommended products
        seg_products = []
        # Get the list of unique products for each segment
        Segment_products = list(self.rewardFull[self.rewardFull['Segment'] == seg]['StockCode'].unique())
        # Get the list of top n products based on value
        topProducts = self.sortlist(nproducts,seg)
        # Start a loop to get the required number of products
        while len(seg_products) < nproducts:
            # First find a probability
            probability = np.random.rand()
            if probability >= epsilon:
                # print(topProducts)
                # The top product would be first product in the list
                prod = topProducts[0]
                # Append the selected product to the list
                seg_products.append(prod)
                # Remove the top product once appended
                topProducts.pop(0)
                # Ensure that seg_products is unique
                seg_products = list(OrderedDict.fromkeys(seg_products))
            else:
                # If the probability is less than epsilon value randomly sample one product
                prod = sample(Segment_products, 1)[0]
                seg_products.append(prod)
                # Ensure that seg_products is unique
                seg_products = list(OrderedDict.fromkeys(seg_products))
        return seg_products

The inputs to the method are the segment, number of products to be recommended and the epsilon value which determines exploration and exploitation as shown in line 191. In line 195, we get the list of the products for the segment. This list is from where products are sampled during the exploration phase. We also get the list of top products which needs to be recommended in line 197, using the sortlist method we defined earlier. In lines 199-218 we implement the exploitation and exploration processes we discussed during the prototyping phase and finally we return the list of top products for recommendation.

The next method which we will explore is the one to update dictionaries after the recommendation process.

# This is the method for updating the dictionaries after recommendation
    def dicUpdater(self,prodList, stateId):
        for prod in prodList:
            # Check if the product is in the dictionary
            if prod in list(self.countDic[stateId].keys()):
                # Update the count by 1
                self.countDic[stateId][prod] += 1
            else:
                self.countDic[stateId][prod] = 1
            if prod in list(self.recoCountdic[stateId].keys()):
                # Update the recommended products with 1
                self.recoCountdic[stateId][prod] += 1
            else:
                # Initialise the recommended products as 1
                self.recoCountdic[stateId][prod] = 1
            if prod not in list(self.polDic[stateId].keys()):
                # Initialise the value as 0
                self.polDic[stateId][prod] = 0
            if prod not in list(self.rewDic[stateId].keys()):
                # Initialise the reward dictionary as 0
                self.rewDic[stateId][prod] = GaussianDistribution(loc=0, scale=1, size=1)[0].round(2)
        print("[INFO] Completed the initial dictionary updates")

The inputs to this method, as in line 221, are the list of products to be recommended and the state Id. From lines 222-234, we iterate through each of the recommended product and increament the count in the dictionary if the product exists in the dictionary or initialize the count to 1 if the product wasnt available. Later on in lines 235-240, we initialise the value dictionary and the reward dictionary if the products are not available in them.

The next method we will see is the one for initializing the dictionaries in case the context dosent exist.

    def dicAdder(self,prodList, stateId):
        # Loop through the product list
        for prod in prodList:
            # Initialise the count as 1
            self.countDic[stateId][prod] = 1
            # Initialise the value as 0
            self.polDic[stateId][prod] = 0
            # Initialise the recommended products as 1
            self.recoCountdic[stateId][prod] = 1
            # Initialise the reward dictionary as 0
            self.rewDic[stateId][prod] = GaussianDistribution(loc=0, scale=1, size=1)[0].round(2)
        print("[INFO] Completed the dictionary initialization")
        # Next update the collections with the respective updates
        # Updating the quantity collection
        db.rlQuantdic.insert_one({stateId: self.countDic[stateId]})
        # Updating the recommendation tracking collection
        db.rlRecotrack.insert_one({stateId: self.recoCount[stateId]})
        # Updating the value function collection for the products
        db.rlValuedic.insert_one({stateId: self.polDic[stateId]})
        # Updating the rewards collection
        db.rlRewarddic.insert_one({stateId: self.rewDic[stateId]})
        print('[INFO] Completed updating all the collections')

If the state Id dosent exist, the dictionaries are initialised as seen in lines 147-155. Once the dictionaries are initialised, MongoDb data bases are updated in lines 259-265.

The next method which we are going to explore is one of the main methods which integrates all the methods we have seen so far. This methods implements the recomendation process. Let us explore this method.

# Method to sample a stateID and then initialize the dictionaries
    def rlRecommender(self):
        # First sample a stateID
        stateId = self.stateId
        # Start the recommendation process
        if len(self.polDic[stateId]) > 0:
            print("The context exists")
            # Implement the sampling of products based on exploration and exploitation
            seg_products = self.sampProduct(self.seg, self.conf["nProducts"],self.conf["epsilon"])
            # Check if the recommendation count collection exist
            recoCol = self.recoCollChecker()
            print('Recommendation collection existing :',recoCol)
            # Update the dictionaries of values and rewards
            self.dicUpdater(seg_products, stateId)
        else:
            print("The context dosent exist")
            # Get the list of relavant products
            seg_products = self.segProduct(self.seg, conf["nProducts"])
            # Add products to the value dictionary and rewards dictionary
            self.dicAdder(seg_products, stateId)
        print("[INFO] Completed the recommendation process")

        return seg_products

The first step in the process is to get the state Id ( line 271 ) based on which we have to do all the recommendations. Once we have the state Id, we check if it is an existing state id in line 273. If it is an existing state Id we get the list of ‘n’ products for recommendation using the sampProduct method we saw earlier, where we implement exploration and exploitation. Once we get the products we initialise the recommendation collection in line 278. Finally we update all dictionaries using the dicUpdater method in line 281.

From lines 282-287, we implement a similar process when the state Id dosent exist. The only difference in this case is in the initialisation of the dictionaries in line 287, where we use the dicAdder method.

Once we complete the recommendation process, we get into simulating the customer action.

# Function to initiate customer action
    def custAction(self,segproducts):
        print('[INFO] getting the customer action')
        # Sample a value to get how many products will be clicked
        click_number = np.random.choice(np.arange(0, 10),
                                        p=[0.50, 0.35, 0.10, 0.025, 0.015, 0.0055, 0.002, 0.00125, 0.00124, 0.00001])
        # Sample products which will be clicked based on click number
        click_list = sample(segproducts, click_number)

        # Sample for buy values
        buy_number = np.random.choice(np.arange(0, 10),
                                      p=[0.70, 0.15, 0.10, 0.025, 0.015, 0.0055, 0.002, 0.00125, 0.00124, 0.00001])
        # Sample products which will be bought based on buy number
        buy_list = sample(segproducts, buy_number)

        return click_list, buy_list

Lines 296-305 implements the processes for simulating the list of products which are bought and browsed by the customer based on the recommendation we made. The method returns the list of products which were browsed through and also the one which were bought. For detailed explanations on these methods please refer the previous post

The next methods we will explore are the ones related to the value updation of the recommendation system.

    def getReward(self,loc):
        rew = GaussianDistribution(loc=loc, scale=1, size=1)[0].round(2)
        return rew

    def saPolicy(self,rew, prod):
        # This function gets the relavant algorithm for the policy update
        # Get the current value of the state
        vcur = self.polDic[self.stateId][prod]
        # Get the counts of the current product
        n = self.recoCountdic[self.stateId][prod]
        # Calculate the new value
        Incvcur = (1 / n) * (rew - vcur)
        return Incvcur

The getReward method on line 309 is to generate a reward from a gaussian distribution centred around the reward value. We will see the use of this method in subsequent methods.

The saPolicy method in lines 313-321 updates the value of the state based on the simple averaging method in line 320. We have already seen these methods in our prototyping phase in the previous post.

Next we will see the method which uses both the above methods.

    def valueUpdater(self,seg_products, loc, custList, remove=True):
        for prod in custList:
            # Get the reward for the bought product. The reward will be centered around the defined reward for each action
            rew = self.getReward(loc)
            # Update the reward in the reward dictionary
            self.rewDic[self.stateId][prod] += rew
            # Update the policy based on the reward
            Incvcur = self.saPolicy(rew, prod)
            self.polDic[self.stateId][prod] += Incvcur
            # Remove the bought product from the product list
            if remove:
                seg_products.remove(prod)
        return seg_products

The inputs to this method are the recommended list of products, the mean reward ( click, buy or ignore), the corresponding list ( click list or buy list) and a flag to indicate if the product has to be removed from the recommendation list or not.

We interate through all the products in the customer action list in line 324 and then gets the reward in line 326. Once the reward is incremented in the reward dictionary in line 328, we get the incremental value in line 330 and this is updated in the value dictionary in line 331. If the flag is True, we remove the product from the recommended list and the finally returns the remaining recommendation list.

The next method is the last of the methods and ties the above three methods with the customer action.

# Function to update the reward dictionary and the value dictionary based on customer action
    def rewardUpdater(self, seg_products,custBuy=[], custClick=[]):
        # Check if there are any customer purchases
        if len(custBuy) > 0:
            seg_products = self.valueUpdater(seg_products, self.conf['buyReward'], custBuy)
            # Repeat the same process for customer click
        if len(custClick) > 0:
            seg_products = self.valueUpdater(seg_products, self.conf['clickReward'], custClick)
            # For those products not clicked or bought, give a penalty
        if len(seg_products) > 0:
            custList = seg_products.copy()
            seg_products = self.valueUpdater(seg_products, -2, custList,False)
        # Next update the collections with the respective updates
        print('[INFO] Updating all the collections')
        # Updating the quantity collection
        db.rlQuantdic.replace_one({self.stateId: {'$exists': True}}, {self.stateId: self.countDic[self.stateId]})
        # Updating the recommendation tracking collection
        db.rlRecotrack.replace_one({self.stateId: {'$exists': True}}, {self.stateId: self.recoCountdic[self.stateId]})
        # Updating the value function collection for the products
        db.rlValuedic.replace_one({self.stateId: {'$exists': True}}, {self.stateId: self.polDic[self.stateId]})
        # Updating the rewards collection
        db.rlRewarddic.replace_one({self.stateId: {'$exists': True}}, {self.stateId: self.rewDic[self.stateId]})
        print('[INFO] Completed updating all the collections')

In lines 340-348, we update the value based on the number of products bought, clicked and ignored. Once the value dictionaries are updated, the respective MongoDb dictionaries are updated in lines 352-358.

With this we have covered all the methods which are required for implementing the self learning recommendation system. Let us summarise our learning so far in this post.

  • Created the states and updated MongoDB with the states data. We used the historic data for initialisation of values.
  • Implemented the recommendation process by getting a list of products to be recommended to the customer
  • Explored customer response simulation wherein the customer response to the recommended products were implemented.
  • Updated the value functions and reward functions after customer response
  • Updated Mongo DB collections after the completion of the process for a customer.

What next ?

We are coming to the fag end of our series. The next post is where we tie all these methods together in the main driver file and see how these processes are implmented. We will also run the script on the terminal and observe the results. Once the application implementation is done, we will also explore avenues to deploy the application. Watch this space for the last post of the series.

Please subscribe to this blog post to get notifications when the next post is published.

You can also subscribe to our Youtube channel for all the videos related to this series.

The complete code base for the series is in the Bayesian Quest Git hub repository

Do you want to Climb the Machine Learning Knowledge Pyramid ?

Knowledge acquisition is such a liberating experience. The more you invest in your knowledge enhacement, the more empowered you become. The best way to acquire knowledge is by practical application or learn by doing. If you are inspired by the prospect of being empowerd by practical knowledge in Machine learning, subscribe to our Youtube channel

I would also recommend two books I have co-authored. The first one is specialised in deep learning with practical hands on exercises and interactive video and audio aids for learning

This book is accessible using the following links

The Deep Learning Workshop on Amazon

The Deep Learning Workshop on Packt

The second book equips you with practical machine learning skill sets. The pedagogy is through practical interactive exercises and activities.

The Data Science Workshop Book

This book can be accessed using the following links

The Data Science Workshop on Amazon

The Data Science Workshop on Packt

Enjoy your learning experience and be empowered !!!!

VIII : Build and deploy data science products: Machine translation application -Build and deploy using Flask

Source shutterstock.com

One measure of success will be the degree to which you build up others

This is the last post of the series and in this post we finally build and deploy our application we painstakingly developed over the past 7 posts . This series comprises of 8 posts.

  1. Understand the landscape of solutions available for machine translation
  2. Explore sequence to sequence model architecture for machine translation.
  3. Deep dive into the LSTM model with worked out numerical example.
  4. Understand the back propagation algorithm for a LSTM model worked out with a numerical example.
  5. Build a prototype of the machine translation model using a Google colab / Jupyter notebook.
  6. Build the production grade code for the training module using Python scripts.
  7. Building the Machine Translation application -From Prototype to Production : Inference process
  8. Building the Machine Translation application: Build and deploy using Flask : ( This post)

Over the last two posts we covered the factory model and saw how we could build the model during the training phase. We also saw how the model was used for inference. In this section we will take the results of these predictions and build an app using flask. We will progressively work through the different processes of building the application.

Folder Structure

In our journey so far we progressively built many files which were required for the training phase and the inference phase. Now we are getting into the deployment phase were we want to deploy the code we have built into an application. Many of the files which we have built during the earlier phases may not be required anymore in this phase. In addition, we want the application we deploy as light as possible for its performance. For this purpose it is always a good idea to create a seperate folder structure and a new virtual environment for deploying our application. We will only select the necessary files for the deployment purpose. Our final folder structure for this phase will look as follows

Let us progressively build this folder structure and the required files for building our machine translation application.

Setting up and Installing FLASK

When building an application in FLASK , it is always a good practice to create a virtual environment and then complete the application build process within the virtual environment. This way we can ensure that only application specific libraries and packages are deployed into the hosting service. You will see later on that creating a seperate folder and a new virtual environment will be vital for deploying the application in Heroku.

Let us first create a separate folder in our drive and then create a virtual environment within that folder. In a Linux based system, a seperate folder can be created as follows

$ mkdir mtApp

Once the new directory is created let us change directory into the mtApp directory and then create a virtual environment. A virtual environment can be created on Linux with Python3 with the below script

mtApp $ python3 -m venv mtApp

Here the second mtApp is the name of our virtual environment. Do not get confused with the directory we created with the same name. The virtual environment which we created can be activated as below

mtApp $ source mtApp/bin/activate

Once the virtual environment is enabled we will get the following prompt.

(mtApp) ~$

In addition you will notice that a new folder created with the same name as the virtual environment

Our next task is to install all the libraries which are required within the virtual environment we created.

(mtApp) ~$ pip install flask

(mtApp) ~$ pip install tensorflow

(mtApp) ~$ pip install gunicorn

That takes care of all the installations which are required to run our application. Let us now look through the individual folders and the files within it.

There would be three subfolders under the main application folder MTapp. The first subfolder factoryModel is a subset of the corrsponding folder we maintained during the training phase. The second subfolder mtApp is the one created when the virtual environment was created. We dont have to do anything with that folder. The third folder templates is a folder specifically for the flask application. The file app.py is the driver file for the flask application. Let us now looks into each of the folders.

Folder 1 : factoryModel:

The subfolders and files under the factoryModel folder are as shown below. These subfolders and its files are the same as what we have seen during the training phase.

The config folder contains the __init__.py file and the configuration file mt_config.py we used during the training and inference phases.

The output folder contains only a subset of the complete output folder we saw during the inference phase. We need only those files which are required to translate an input German string to English string. The model file we use is the one generated after the training phase.

The utils folder has the same helperFunctions script which we used during the training and inference phase.

Folder 2 : Templates :

The templates folder has two html templates which are required to visualise the outputs from the flask application. We will talk more about the contents of the html file in a short while along with our discussions on the flask app.

Flask Application

Now its time to get to the main part of this article, which is, building the script for the flask application. The code base for the functionalities of the application will be the same as what we have seen during the inference phase. The difference would be in terms of how we use the predictions and visualise them on to the web browser using the flask application.

Let us now open a new file and name is app.py. Let us start building the code in this file

'''
This is the script for flask application
'''

from tensorflow.keras.models import load_model
from factoryModel.config import mt_config as confFile
from factoryModel.utils.helperFunctions import *
from flask import Flask,request,render_template

# Initializing the flask application
app = Flask(__name__)

## Define the file path to the model
modelPath = confFile.MODEL_PATH

# Load the model from the file path
model = load_model(modelPath)

Lines 5-8 imports the required libraries for creating the application

Lines 11 creates the application object ‘app’ as an instance of the class ‘Flask’. The (__name__) variable passed to the Flask class is a predefined variable used in Python to set the name of the module in which it is used.

Line 14 we load the configuration file from the config folder.

Line 17 The model which we created during the training phase is loaded using the load_model() function in Keras.

Next we will load the required pickle files we saved after the training process. In lines 20-22 we intialize the paths to all the files and variables we saved as pickle files during the training phase. These paths are defined in the configuration file. Once the paths are initialized the required files and variables are loaded from the respecive pickle files in lines 24-27. We use the load_files() function we defined in the helper function script for loading the pickle files. You can notice that these steps are same as the ones we used during the inference process.

In the next lines we will explore the visualisation processes for flask application.

@app.route('/')
def home():
	return render_template('home.html')

Lines 29:31 is a feature called the ‘decorator’. A decorator is used to modify the function which comes after it. The function which follows the decorator is a very simple function which returns the html template for our landing page. The landing page of the application is a simple text box where the source language (German) has to be entered. The purpose of the decorator is to build a mapping between the function and the url for the landing page. The URL’s are defined through another important component called ‘routes’ . ‘Routes’ modules are objects which configures the webpages which receives inputs and displays the returned outputs. There are two ‘routes’ which are required for this application, one corresponding to the home page (‘/’) and the second one mapping to another webpage called ‘/translate. The way the decorator, the route and the associated function works together is as follows. The decorator first defines the relationship between the function and the route. The function returns the landing page and route shows the location where the landing page has to be displayed.

Next we will explore the next decorator which return the predictions

@app.route('/translate', methods=['POST', 'GET'])
def get_translation():
    if request.method == 'POST':

        result = request.form
        # Get the German sentence from the Input site
        gerSentence = str(result['input_text'])
        # Converting the text into the required format for prediction
        # Step 1 : Converting to an array
        gerAr = [gerSentence]
        # Clean the input sentence
        cleanText = cleanInput(gerAr)
        # Step 2 : Converting to sequences and padding them
        # Encode the inputsentence as sequence of integers
        seq1 = encode_sequences(Ger_tokenizer, int(Ger_stdlen), cleanText)
        # Step 3 : Get the translation
        translation = generatePredictions(model,Eng_tokenizer,seq1)
        # prediction = model.predict(seq1,verbose=0)[0]

        return render_template('result.html', trans=translation)

Line 33. Our application is designed to accept German sentences as input, translate it to English sentences using the model we built and output the prediction back to the webpage. By default, the routes decorator only receives input i.e ‘GET’ requests. In order to return the predicted words, we have to define a new method in the decorator route called ‘POST’. This is done through the parameters methods=['POST','GET'] in the decorator.

Line 34. is the main function which translates the input German sentences to English sentences and then display the predictions on to the webpage.

Line 35, defines the ‘if’ method to ascertain that there is a ‘POST’ method which is involved in the operation. The next line is where we define the web form which is used for getting the inputs from the application. Web forms are like templates which are used for receiving inputs from the users and also returning the output.

In Line 37 we define the request.form into a new variable called result. All the outputs from the web forms will be accessible through the variable result.There are two web forms which we use in the application ‘home.html’ and ‘result.html’.

By default the webforms have to reside in a folder called Templates. Before we proceed with the rest of the code within the function we have to understand the webforms. Therefore let us build them. Open a new file and name it home.html and copy the following code.

<!DOCTYPE html>

<html>
<title>Machine Translation APP</title>
<body>
<form action = "/translate" method= "POST">

	<h3> German Sentence: </h3>

	<th> <input name='input_text' type="text" value = " " /> </th>

	<p><input type = "submit" value = "submit" /></p>

</form>
</body>
</html>

The prediction process in our application is initiated when we get the input German text from the ‘home.html’ form. In ‘home.html’ we define the variable name ( ‘input_text’ : line 10 in home.html) for getting the German text as input. A default value can also be mentioned using the variable value which will be over written when a new text is given as input. We also specify a submit button for submitting the input German sentence through the form, line 12.

Line 39 : As seen in line 37, the inputs from the web form will be stored in the variable result. Now to access the input text which is stored in a variable called ‘input_text’ within home.html, we have to call it as ‘input_text’ from the result variable ( result['input_text']. This input text is there by stored into a variable ‘gerSentence’ as a string.

Line 42 the string object we received from the earlier line is converted to a list as required during prediction process.

Line 44, we clean the input text using the cleanInput() function we import from the helperfunctions. After cleaning the text we need to convert the input text into a sequence of integers which is done in line 47. Finally in line 49, we generate the predicted English sentences.

For visualizing the translation we use the second html template result.html. Let us quickly review the template

<!DOCTYPE html>
<html>
<title>Machine Translation APP</title>

    <body>
          <h3> English Translation:  </h3>
            <tr>
                <th> {{ trans }} </th>
            </tr>
    </body>
</html>

This template is a very simple one where the only varible of interest is on line 8 which is the variable trans.

The translation generated is relayed to result.html in line 51 by assigning the translation to the parameter trans .

if __name__ == '__main__':
    app.debug = True
    app.run()

Finally to run the app, the app.run() method has to be invoked as in line 56.

Let us now execute the application on the terminal. To execute the application run $ python app.py on the terminal. Always ensure that the terminal is pointing to the virtual environment we initialized earlier.

When the command is executed you should expect to get the following screen

Click the url or copy the url on a browser to see the application you build come live on your browser.

Congratulations you have your application running on the browser. Keep entering the German sentences you want to translate and see how the application performs.

Deploying the application

You have come a long way from where you began. You have now built an application using your deep learning model. Now the next question is where to go from here. The obvious route is to deploy the application on a production server so that your application is accessible to users on the web. We have different deployment options available. Some popular ones are

  • Heroku
  • Google APP engine
  • AWS
  • Azure
  • Python Anywhere …… etc.

What ever be the option you choose, deploying an application of this size will be best achieved by subscribing a paid service on any of these options. However just to go through the motions and demonstrate the process let us try to deploy the application on the free option of Heroku.

Deployment Process on Heroku

Heroku offers a free version for deployment however there are restrictions on the size of the application which can be hosted as a free service. Unfortunately our application would be much larger than the one allowed on the free version. However, here I would like to demonstrate the process of deploying the application on Heroku.

Step 1 : Creating the Heroku account.

The first step in the process is to create an account with Heroku. This can be done through the link https://www.heroku.com/. Once an account is created we get access to a dashboard which lists all the applications which we host in the platform.

Step 2 : Configuring git

Configuring ‘git’ is vital for deploying applications to Heroku. Git has to be installed first to our local system to make the deployment work. Git can be installed by following instructions in the link https://git-scm.com/book/en/v2/Getting-Started-Installing-Git.

Once ‘git’ is installed it has to be configured with your user name and email id.

$ git config –global user.name “user.name”

$ git config –global user.email userName@mail.com

Step 3 : Installing Heroku CLI

The next step is to install the Heroku CLI and the logging in to the Heroku CLI. The detailed steps which are involved for installing the Heroku CLI are given in this link

https://devcenter.heroku.com/articles/heroku-cli

If you are using Ubantu system you can install Heroku CLI using the script below

$ sudo snap install heroku --classic

Once Heroku is installed we need to log into the CLI once. This is done in the terminal with the following command

$ heroku login

Step 4 : Creating the Procfile and requirements.txt

There is a file called ‘Procfile’ in the root folder of the application which gives instructions on starting the application.

Procfile and requirements.txt in the application folder

The file can be created using any text editor and should be saved in the name ‘Procfile’. No extension should be specified for the file. The contents of the file should be as follows

web: gunicorn app:app --log-file

Another important pre-requisite for the Heroku application is a file called ‘requirements.txt’. This is a file which lists down all the dependencies which needs to be installed for running the application. The requirements.txt file can be created using the below command.

$ pip freeze > requirements.txt

Step 5 : Initializing git and copying the required dependent files to Heroku

The above steps creates the basic files which are required for running the application. The next task is to initialize git on the folder. To initialize git we need to go into the root folder where the app.py file exists and then initialize it with the below command

$ git init

Step 6 : Create application instance in Heroku

In order for git to push the application file to the remote Heroku server, an instance of the application needs to be created in Heroku. The command for creating the application instance is as shown below.

$ heroku create {application name}

Please replace the braces with the application name of your choice. For example if the application name you choose is 'gerengtran', it has to be enabled as follows

$ heroku create gerengtran

Step 7 : Pushing the application files to remote server

Once git is initialized and an instance of the application is created in Heroku, the application files can be set up in remote Heroku server by the following commands.

$ heroku git:remote -a {application name}

Please note that ‘application_name’ is the name of the application which you have chosen earlier. What ever name you choose will be the name of the application in Heroku. The external link to your application will be in the name which you choose here.

Step 8 : Deploying the application and making it available as a web app

The final step of the process is to complete the deployment on Heroku and making the application available as a web app. This process starts with the command to add all the changes which you made to git.

$ git add .

Please note that there is a full stop( ‘.’ ) as part of the script after ‘add’ with a space in between .

After adding all the changes, we need to commit all the changes before finally deploying the application.

$ git commit -am "First submission"

The deployment will be completed with the below script after which the application will be up and running as a web app.

$ git push heroku master

When the files are pushed, if the deployment is successful you will get a url which is the link to the application. Alternatively, you can also go to Heroku console and activate your application. Below is the view of your console with all the applications listed. The application with the red box is the application which has been deployed

If you click on the link of the application ( red box) you get the link where the application can be open.

When the open app button is clicked the application is opened in a browser.

Wrapping up the series

With this we have achieved a good milestone of building an application and deploying it on the web for others to consume. I am a strong believer that learning data science should be to enrich products and services. And the best way to learn how to enrich products and services is to build it yourselves at a smaller scale. I hope you would have gained a lot of confidence by building your application and then deploying them on the web. Before we bid adeau, to this series let us summarise what we have achieved in this series and list of the next steps

In this series we first understood the solution landscape of machine translation applications and then understood different architecture choices. In the third and fourth posts we dived into the mathematics of a LSTM model where we worked out a toy example for deriving the forward pass and backpropagation. In the subsequent posts we got down to the tasks of building our application. First we built a prototype and then converted it into production grade code. Finally we wrapped the functionalities we developed in a Flask application and understood the process of deploying it on Heroku.

You have definitely come a long way.

However looking back are there avenues for improvement ? Absolutely !!!

First of all the model we built is a simple one. Machine translation is a complex process which requires lot more sophisticated models for better results. Some of the model choices you can try out are the following

  1. Change the model architecture. Experiment with different number of units and number of layers. Try variations like bidirectional LSTM
  2. Use attention mechanisms on the LSTM layers. Attention mechanism is see to have given good performance on machine translation tasks
  3. Move away from sequence to sequence models and use state of the art models like Transformers.

The second set of optimizations you can try out are on the vizualisations of the flask application. The templates which are used here are very basic templates. You can further experiment with different templates and make the application visually attractive.

The final improvement areas are in the choices of deployment platforms. I would urge you to try out other deployment choices and let me know the results.

I hope all of you enjoyed this series. I definitely enjoyed writing this post. Hope it benefits you and enable you to improve upon the methods used here.

I will be back again with more practical application building series like this. Watch this space for more

You can download the code for the deployment process from the following link

https://github.com/BayesianQuest/MachineTranslation/tree/master/Deployment/MTapp

Do you want to Climb the Machine Learning Knowledge Pyramid ?

Knowledge acquisition is such a liberating experience. The more you invest in your knowledge enhacement, the more empowered you become. The best way to acquire knowledge is by practical application or learn by doing. If you are inspired by the prospect of being empowerd by practical knowledge in Machine learning, I would recommend two books I have co-authored. The first one is specialised in deep learning with practical hands on exercises and interactive video and audio aids for learning

This book is accessible using the following links

The Deep Learning Workshop on Amazon

The Deep Learning Workshop on Packt

The second book equips you with practical machine learning skill sets. The pedagogy is through practical interactive exercises and activities.

This book can be accessed using the following links

The Data Science Workshop on Amazon

The Data Science Workshop on Packt

Enjoy your learning experience and be empowered !!!!

VI : Build and deploy data science products: Machine translation application – From prototype to production. Introduction to the factory model

Source: brainyquote.com

This is the sixth part of the series where we continue on our pursuit to build a machine translation application. In this post we embark on a transformation process where in we transform our prototype into a production grade code.

This series comprises of 8 posts.

  1. Understand the landscape of solutions available for machine translation
  2. Explore sequence to sequence model architecture for machine translation.
  3. Deep dive into the LSTM model with worked out numerical example.
  4. Understand the back propagation algorithm for a LSTM model worked out with a numerical example.
  5. Build a prototype of the machine translation model using a Google colab / Jupyter notebook.
  6. Build the production grade code for the training module using Python scripts.( This post)
  7. Building the Machine Translation application -From Prototype to Production : Inference process
  8. Build the machine translation application using Flask and understand the process to deploy the application on Heroku

In this section we will see how we can take the prototype which we built in the last article into a production ready code. In the prototype building phase we were developing our code on a Jupyter/Colab notebook. However if we have to build an application and deploy it, notebooks would not be very effective. We have to convert the code we built on the notebook into production grade code using python scripts. We will be progressively building the scripts using a process, I call, as the factory model. Let us see what a factory model is.

Factory Model

A Factory model is a modularized process of generating business outcomes using machine learning models. There are some distinct phases in the process which includes

  1. Ingestion/Extraction process : Process of getting data from source systems/locations
  2. Transformation process : Transformation process entails transforming raw data ingested from multiple sources into a form fit for the desired business outcome
  3. Preprocessing process: This process involves basic level of cleaning of the transformed data.
  4. Feature engineering process : Feature engineering is the process of converting the preprocessed data into features which are required for model training.
  5. Training process : This is the phase where the models are built from the featurized data.
  6. Inference process : The models which were built during the training phase is then utilized to generate the desired business outcomes during the inference process.
  7. Deployment process : The results of the inference process will have to be consumed by some process. The consumer of the inferences could be a BI report or a web service or an ERP application or any downstream applications. There is a whole set of process which is involved in enabling the down stream systems to consume the results of the inference process. All these steps are called the deployment process.

Needless to say all these processes are supported by an infrastructure layer which is also called the data engineering layer. This layer looks at the most efficient and effective way of running all these processes through modularization and parallelization.

All these processes have to be designed seamlessly to get the business outcomes in the most effective and efficient way. To take an analogy its like running a factory where raw materials gets converted into a finished product and thereby gets consumed by the end customers. In our case, the raw material is the data, the product is the model generated from the training phase and the consumers are any business process which uses the outcomes generated from the model.

Let us now see how we can execute the factory model to generate the business outcomes.

Project Structure

Before we dive deep into the scripts, let us look at our project structure.

Our root folder is the Machine Translation folder which contains two sub folders Data and factoryModel. The Data subfolder contains the raw data. The factoryModel folder contains different subfolders containing scripts for our processes. We will be looking at each of these scripts in detail in the subsequent sections. Finally we have two driver files mt_driver_train.py which is the driver file for the training process and mt_Inference.py which is the driver file for the inference process.

Let us first dive into the training phase scripts.

Training Phase

The first part of the factory model is the training phase which comprises of all the processes till the creation of the model. We will start off by building the supporting files and folders before we get into the driver file. We will first start with the configuration file.

Configuration file

When we were working with the notebook files, we were at a liberty to change the pararmeters we wanted to vary, say for example the path to the input file or some hyperparameters like the number of dimensions of the embedding vector, on the notebook itself. However when an application is in production we would not have the luxury to change the parameters and hyperparameters directly in the code base. To get over this problem we use the configuration files. We consolidate all the parameters and hyperparameters of the model on to the configuration file. All processes will pick the parameters from the configuration file for further processing.

The configuration file will be inside the config folder. Let us now build the configuration file.

Open a word editor like notepad++ or any other editor of your choice and open a new file and name it mt_config.py. Let us start adding the below code in this file.

'''
This is the configuration file for storing all the application parameters
'''

import os
from os import path


# This is the base path to the Machine Translation folder
BASE_PATH = '/media/acer/7DC832E057A5BDB1/JMJTL/Tomslabs/BayesianQuest/MT/MachineTranslation'
# Define the path where data is stored
DATA_PATH = path.sep.join([BASE_PATH,'Data/deu.txt'])

Lines 5 and 6, we import the necessary library packages.

Line 10, we define the base path for the application. You need to change this path based on your specific path to the application. Once the base path is set, the rest of the paths will be derived out from it. In Line 12, we define the path to the raw data set folder. Note that we just join the name of the data folder and the raw text file with the base path to get the data path. We will be using the data path to read in the raw data.

In the config folder there will be another file named __init__.py . This is a special file which tells Python to treat the config folder as part of the package. This file inside this folder will be an empty file with no code in it

Loading Data

The next helper files we will build are those for loading raw files and preprocessing. The code we use for these purposes are the same code which we used for building the prototype. This file will reside in the dataLoader folder

In your text editor open a new file and name it as datasetloader.py and then add the below code into it

'''
Factory Model for Machine translation preprocessing.
This is the script for loading the data and preprocessing data
'''

import string
import re
from pickle import dump
from unicodedata import normalize
from numpy import array

# Creating the class to load data and then do the preprocessing as sequence of steps

class textLoader:
	def __init__(self , preprocessors = None):
		# This init method is to store the text preprocessing pipeline
		self.preprocessors = preprocessors
		# Initializing the preprocessors as an empty list of the preprocessors are None
		if self.preprocessors is None:
			self.preprocessors = []

	def loadDoc(self,filepath):
		# This is the function to read the file from the path provided
		# Open the file
		file = open(filepath,mode = 'rt',encoding = 'utf-8')
		# Reading the text
		text = file.read()
		#Once the file is read, applying the preprocessing steps one by one
		if self.preprocessors is not None:
			# Looping over all the preprocessing steps and applying them on the text data
			for p in self.preprocessors:
				text = p.preprocess(text)

		# Closing the file
		file.close()

		# Returning the text after all the preprocessing
		return text

Before addressing the code block line by line, let us get a big picture perspective of what we are trying to accomplish. When working with text you would have realised that different sources of raw text requires different preprocessing treatments. A preprocessing method which we have used for one circumstance may not be warranted in a different one. So in this code block we are building a template called textLoader, which reads in raw data and then applies different preprocessing steps like a pipeline as the situation warrants. Each of the individual preprocessing steps would be defined seperately. The textLoader class first reads in the data and then applies the selected preprocessing one after the other. Let us now dive into the details of the code.

Lines 6 to 10 imports all the necessary library packages for the process.

Line 14 we define the textLoader class. The constructor in line 15 takes the text preprocessor pipeline as the input. The prepreprocessors are given as lists. The default value is taken as None. The preprocessors provided in the constructor is initialized in line 17. Lines 19-20 initializes an empty list if the preprocessor argument is none. If you havent got a handle of why the preprocessors are defined this way, it is ok. This will be more clear when we define the actual preprocessors. Just hang on till then.

From line 22 we start the first function within this class. This function is to read the raw text and the apply the processing pipeline. Lines 25 – 27, where we open the text file and read the text is the same as what we defined during the prototype phase in the last post. We do a check to see if we have defined any preprocessor pipeline in line 29. If there are any pipeline defined those are applied on the text one by one in lines 31-32. The method .preprocess is specific to each of the preprocessor in the pipeline. This method would be clear once we take a look at each of the preprocessors. We finally close the raw file and the return the processed text in lines 35-38.

The __init__.py file inside this folder will contain the following line for importing the textLoader class from the datasetloader.py file for any calling script.

from .datasetloader import textLoader

Processing Data : Preprocessing pipeline construction

Next we will create the files for preprocessing the text. In the last section we saw how the raw data was loaded and then preprocessing pipeline was applied. In this section we look into the preprocessing pipeline. The folder structure will be as shown in the figure.

There would be three preprocessors classes for processing the raw data.

  • SentenceSplit : Preprocessor to split raw text into pair of English and German sentences. This class is inside the file splitsentences.py
  • cleanData : Preprocessor to apply cleaning steps like removing punctuations, removing whitespaces which is included in the datacleaner.py file.
  • TrainMaker : Preprocessor to tokenize text and then finally prepare the train and validation sets contined in the tokenizer.py file

Let us now dive into each of the preprocessors.

Open a new file and name it splitsentences.py. Add the following code to this file.

'''
Script for preprocessing of text for Machine Translation
This is the class for splitting the text into sentences
'''

import string
from numpy import array

class SentenceSplit:
	def __init__(self,nrecords):
		# Creating the constructor for splitting the sentences
		# nrecords is the parameter which defines how many records you want to take from the data set
		self.nrecords = nrecords

	# Creating the new function for splitting the text
	def preprocess(self,text):
		sen = text.strip().split('\n')
		sen = [i.split('\t') for i in sen]
		# Saving into an array
		sen = array(sen)
		# Return only the first two columns as the third column is metadata. Also select the number of rows required
		return sen[:self.nrecords,:2]

This is the first or our preprocessors. This preprocessor splits the raw text and finally outputs an array of English and German sentence pairs.

After we import the required packages in lines 6-7, we define the class in line 9. We pass a variable nrecords to the constructor to subset the raw text and select number of rows we want to include for training.

The preprocess function starts in line 16. This is the function which we were accessing in line 32 of the textLoader class which we discussed in the last section. The rest is the same code we have used in the prototype building phase which includes

  • Splitting the text into sentences in line 17
  • Splitting each sentece on tab spaces to get the German and English sentences ( line 18)

Finally we convert the processed sentences into an array and return only the first two columns of the array. Please note that the third column contains metadata of each line and therefore we exclude it from the returned array. We also subset the array based on the number of records we want.

Now that the first preprocessor is complete,let us now create the second preprocessor.

Open a new file and name it datacleaner.py and copy the below code.

'''
Script for preprocessing data for Machine Translation application
This is the class for removing the punctuations from sentences and also converting it to lower cases
'''

import string
from numpy import array
from unicodedata import normalize

class cleanData:
	def __init__(self):
		# Creating the constructor for removing punctuations and lowering the text
		pass

	# Creating the function for removing the punctuations and converting to lowercase
	def preprocess(self,lines):
		cleanArray = list()
		for docs in lines:
			cleanDocs = list()
			for line in docs:
				# Normalising unicode characters
				line = normalize('NFD', line).encode('ascii', 'ignore')
				line = line.decode('UTF-8')
				# Tokenize on white space
				line = line.split()
				# Removing punctuations from each token
				line = [word.translate(str.maketrans('', '', string.punctuation)) for word in line]
				# convert to lower case
				line = [word.lower() for word in line]
				# Remove tokens with numbers in them
				line = [word for word in line if word.isalpha()]
				# Store as string
				cleanDocs.append(' '.join(line))
			cleanArray.append(cleanDocs)
		return array(cleanArray)

This preprocessor is to clean the array of German and English sentences we received from the earlier preprocessor. The cleaning steps are the same as what we have seen in the previous post. Let us quickly dive in and understand the code block.

We start of by defining the cleanData class in line 10. The preprocess method starts in line 16 with the array from the previous preprocessing step as the input. We define two placeholder lists in line 17 and line 19. In line 20 we loop through each of the sentence pair of the array and the carry out the following cleaning operations

  • Lines 22-23, normalise the text
  • Line 25 : Split the text to remove the whitespaces
  • Line 27 : Remove punctuations from each sentence
  • Line 29: Convert the text to lower case
  • Line 31: Remove numbers from text

Finally in line 33 all the tokens are joined together and appended into the cleanDocs list. In line 34 all the individual sentences are appended into the cleanArray list and converted into an array which is returned in line 35.

Let us now explore the third preprocessor.

Open a new file and name it tokenizer.py . This file is pretty long and therefore we will go over it function by function. Let us explore the file in detail

'''
This class has methods for tokenizing the text and preparing train and test sets
'''

import string
import numpy as np
from numpy import array
from tensorflow.keras.preprocessing.text import Tokenizer
from tensorflow.keras.preprocessing.sequence import pad_sequences
from sklearn.model_selection import train_test_split


class TrainMaker:
	def __init__(self):
		# Creating the constructor for creating the tokenizers
		pass

	# Creating an internal function for tokenizing the text
	def tokenMaker(self,text):
		tokenizer = Tokenizer()
		tokenizer.fit_on_texts(text)
		return tokenizer

We down load all the required packages in lines 5-10, after which we define the constructor in lines 13-16. There is nothing going on in the constructor so we can conveniently pass it over.

The first function starts on line 19. This is a function we are familiar with in the previous post. This function fits the tokenizer function on text. The first step is to instantiate the tokenizer object in line 20 and then fit the tokenizer object on the provided text in line 21. Finally the tokenizer object which is fit on the text is returned in line 22. This function will be used for creating the tokenizer dictionaries for both English and German text.

The next function which we will see is the sequenceMaker. In the previous post we saw how we convert text as sequence of integers. The sequenceMaker function is used for this task.


	# Creating an internal function for encoding and padding sequences

	def sequenceMaker(self,tokenizer,stdlen,text):
		# Encoding sequences as integers
		seq = tokenizer.texts_to_sequences(text)
		# Padding the sequences with respect standard length
		seq = pad_sequences(seq,maxlen=stdlen,padding = 'post')
		return seq

The inputs to the sequenceMaker function on line 26 are the tokenizer , the maximum length of a sequence and the raw text which needs to be converted to sequences. First the text is converted to sequences of integers in line 28. As the sequences have to be of standard legth, they are padded to the maximum length in line 30. The standard length integer sequences is then returned in line 31.


	# Creating another function to find the maximum length of the sequences
	def qntLength(self,lines):
		doc_len = []
		# Getting the length of all the language sentences
		[doc_len.append(len(line.split())) for line in lines]
		return np.quantile(doc_len, .975)

The next function we will define is the function to find the quantile length of the sentences. As seen from the previous post we made the standard length of the sequences equal to the 97.5 % quantile length of the respective text corpus. The function starts in line 34 where the complete text is given as input. We then create a placeholder in line 35. In line 37 we parse through each of the line and the find the total length of the sentence. The length of each sentence is stored in the placeholder list we created earlier. Finally in line 38, the 97.5 quantile of the length is returned to get the standard length.


	# Creating the function for creating tokenizers and also creating the train and test sets from the given text
	def preprocess(self,docArray):
		# Creating tokenizer forEnglish sentences
		eng_tokenizer = self.tokenMaker(docArray[:,0])
		# Finding the vocabulary size of the tokenizer
		eng_vocab_size = len(eng_tokenizer.word_index) + 1
		# Creating tokenizer for German sentences
		deu_tokenizer = self.tokenMaker(docArray[:,1])
		# Finding the vocabulary size of the tokenizer
		deu_vocab_size = len(deu_tokenizer.word_index) + 1
		# Finding the maximum length of English and German sequences
		eng_length = self.qntLength(docArray[:,0])
		ger_length = self.qntLength(docArray[:,1])
		# Splitting the train and test set
		train,test = train_test_split(docArray,test_size = 0.1,random_state = 123)
		# Calling the sequence maker function to create sequences of both train and test sets
		# Training data
		trainX = self.sequenceMaker(deu_tokenizer,int(ger_length),train[:,1])
		trainY = self.sequenceMaker(eng_tokenizer,int(eng_length),train[:,0])
		# Validation data
		testX = self.sequenceMaker(deu_tokenizer,int(ger_length),test[:,1])
		testY = self.sequenceMaker(eng_tokenizer,int(eng_length),test[:,0])
		return eng_tokenizer,eng_vocab_size,deu_tokenizer,deu_vocab_size,docArray,trainX,trainY,testX,testY,eng_length,ger_length

We tie all the earlier functions in the preprocess method starting in line 41. The input to this function is the English, German sentence pair as array. The various processes under this function are

  • Line 43 : Tokenizing English sentences using the tokenizer function created in line 19
  • Line 45 : We find the vocabulary size for the English corpus
  • Lines 47-49 the above two processes are repeated for German corpus
  • Lines 51-52 : The standard lengths of the English and German senetences are found out
  • Line 54 : The array is split to train and test sets.
  • Line 57 : The input sequences for the training set is created using the sequenceMaker() function. Please note that the German sentences are the input variable ( TrainX).
  • Line 58 : The target sequence which is the English sequence is created in this step.
  • Lines 60-61: The input and target sequences are created for the test set

All the variables and the train and test sets are returned in line 62

The __init__.py file inside this folder will contain the following lines

from .splitsentences import SentenceSplit
from .datacleaner import cleanData
from .tokenizer import TrainMaker

That takes us to the end of the preprocessing steps. Let us now start the model building process.

Model building Scripts

Open a new file and name it mtEncDec.py . Copy the following code into the file.

'''
This is the script and template for different models.
'''

from tensorflow.keras.models import Sequential
from tensorflow.keras.layers import LSTM
from tensorflow.keras.layers import Dense
from tensorflow.keras.layers import Embedding
from tensorflow.keras.layers import RepeatVector
from tensorflow.keras.layers import TimeDistributed

class ModelBuilding:
	@staticmethod
	def EncDecbuild(in_vocab,out_vocab, in_timesteps,out_timesteps,units):
		# Initializing the model with Sequential class
		model = Sequential()
		# Initiating the embedding layer for the text
		model.add(Embedding(in_vocab, units, input_length=in_timesteps, mask_zero=True))
		# Adding the first LSTM layer
		model.add(LSTM(units))
		# Using the RepeatVector to map the input sequence length to output sequence length
		model.add(RepeatVector(out_timesteps))
		# Adding the second layer of LSTM
		model.add(LSTM(units, return_sequences=True))
		# Adding the fully connected layer with a softmax layer for getting the probability
		model.add(TimeDistributed(Dense(out_vocab, activation='softmax')))
		# Compiling the model
		model.compile(optimizer='adam', loss='sparse_categorical_crossentropy')
		# Printing the summary of the model
		model.summary()
		return model

The model building scripts is straight forward. Here we implement the encoder decoder model we described extensively in the last post.

We start by importing all the necessary packages in lines 5-10. We then get to the meat of the model by defining the ModelBuilding class in line 12. The model we are using for our application is defined through a function EncDecbuild in line 14. The inputs to the function are the

  • in_vocab : This is the size of the German vocabulary
  • out_vocab : This is the size of the Enblish vocabulary
  • in_timesteps : The standard sequence length of the German sentences
  • out_timesteps : Standard sequence length of Enblish sentences
  • units : Number of hidden units for the LSTM layers.

The progressive building of the model was covered extensively in the last post. Let us quickly run through the same here

  • Line 16 we initialize the sequential class
  • The next layer is the Embedding layer defined in line 18. This layer converts the text to word embedding vectors. The inputs are the German vocabulary size, the dimension required for the word embeddings and the sequence length of the input sequences. In this example we have kept the dimension of the word embedding same as the number of units of LSTM. However this is a parameter which can be experimented with.
  • Line 20, we initialize our first LSTM unit.
  • We then perform the Repeat vector operation in Line 22 so as to make the mapping between the encoder time steps and decoder time steps
  • We add our second LSTM layer for the decoder part in Line 24.
  • The next layer is the dense layer whose output size is equal to the English vocabulary size.(Line 26)
  • Finally we compile the model using ‘adam’ optimizer and then summarise the model in lines 28-30

So far we explored the file ecosystem for our application. Next we will tie all these together in the driver program.

Driver Program

Open a new file and name it mt_driver_train.py and start adding the following code blocks.

'''
This is the driver file which controls the complete training process
'''

from factoryModel.config import mt_config as confFile
from factoryModel.preprocessing import SentenceSplit,cleanData,TrainMaker
from factoryModel.dataLoader import textLoader
from factoryModel.models import ModelBuilding
from tensorflow.keras.callbacks import ModelCheckpoint
from factoryModel.utils.helperFunctions import *

## Define the file path to input data set
filePath = confFile.DATA_PATH

print('[INFO] Starting the preprocessing phase')

## Load the raw file and process the data
ss = SentenceSplit(50000)
cd = cleanData()
tm = TrainMaker()

Let us first look at the library file importing part. In line 5 we import the configuration file which we defined earlier. Please note the folder structure we implemented for the application. The configuration file is imported from the config folder which is inside the folder named factoryModel. Similary in line 6 we import all three preprocessing classes from the preprocessing folder. In line 7 we import the textLoader class from the dataLoader folder and finally in line 8 we import the ModelBuilding class from the models folder.

The first task we will do is to get the path of the files which we defined in the configuration file. We get the path to the raw data in line 13.

Lines 18-20, we instantiate the preprocessor classes starting with the SentenceSplit, cleanData and finally the trainMaker classes. Please note that we pass a parameter to the SentenceSplit(50000) class to indicate that we want only 50000 rows of the raw data, for processing.

Having seen the three preprocessing classes, let us now see how these preprocessors are tied together in a pipeline to be applied sequentially on the raw text. This is achieved in next code block

# Initializing the data set loader class and then executing the processing methods
tL = textLoader(preprocessors = [ss,cd,tm])
# Load the raw data, preprocess it and create the train and test sets
eng_tokenizer,eng_vocab_size,deu_tokenizer,deu_vocab_size,text,trainX,trainY,testX,testY,eng_length,ger_length = tL.loadDoc(filePath)

Line 21 we instantiate the textLoader class. Please note that all the preprocessing classes are given sequentially in a list as the parameters to this class. This way we ensure that each of the preprocessors are implemented one after the other when we implement the textLoader class. Please take some time to review the class textLoader earlier in the post to understand the dynamics of the loading and preprocessing steps.

In Line 23 we implement the loadDoc function which takes the path of the data set as the input. There are lots of processes which goes on in this method.

  • First loads the raw text using the file path provided.
  • On the raw text which is loaded, the three preprocessors are implemented one after the other
  • The last preprocessing step returns all the required data sets like the train and test sets along with the variables we require for modelling.

We now come to the end of the preprocessing step. Next we take the preprocessed data and train the model.

Training the model

We have already built all the necessary scripts required for training. We will tie all those pieces together in the training phase. Enter the following lines of code in our script

### Initiating the training phase #########
# Initialise the model
model = ModelBuilding.EncDecbuild(int(deu_vocab_size),int(eng_vocab_size),int(ger_length),int(eng_length),256)
# Define the checkpoints
checkpoint = ModelCheckpoint('model.h5',monitor = 'val_loss',verbose = 1, save_best_only = True,mode = 'min')
# Fit the model on the training data set
model.fit(trainX,trainY,epochs = 50,batch_size = 64,validation_data=(testX,testY),callbacks = [checkpoint],verbose = 2)

In line 34, we initialize the model object. Please note that when we built the script ModelBuilding was the name of the class and EncDecbuild was the method or function under the class. This is how we initialize the model object in line 34. The various parameter we give are the German and English vocabulary sizes, sequence lenghts of the German and English senteces and the number of units for LSTM ( which is what we adopt for the embedding size also). We define the checkpoint variables in line 36.

We start the model fitting in line 38. At the end of the training process the best model is saved in the path we have defined in the configuration file.

Saving the other files and variables

Once the training is done the model file is stored as a 'model.h5‘ file. However we need to save other files and variables as pickle files so that we utilise them during our inference process. We will create a script where we store all such utility functions for saving data. This script will reside in the utils folder. Open a new file and name it helperfunctions.py and copy the following code.

'''
This script lists down all the helper functions which are required for processing raw data
'''

from pickle import load
from numpy import argmax
from tensorflow.keras.models import load_model
from pickle import dump

def save_clean_data(data,filename):
    dump(data,open(filename,'wb'))
    print('Saved: %s' % filename)

Lines 5-8 we import all the necessary packages.

The first function we will be creating is to dump any files as pickle files which is initiated in line 10. The parameters are the data and the filename of the data we want to save.

Line 11 dumps the data as pickle file with the file name we have provided. We will be using this utility function to save all the files and variables after the training phase.

In our training driver file mt_driver_train.py add the following lines

### Saving the tokenizers and other variables as pickle files
save_clean_data(eng_tokenizer,'eng_tokenizer.pkl')
save_clean_data(eng_vocab_size,'eng_vocab_size.pkl')
save_clean_data(deu_tokenizer,'deu_tokenizer.pkl')
save_clean_data(deu_vocab_size,'deu_vocab_size.pkl')
save_clean_data(trainX,'trainX.pkl')
save_clean_data(trainY,'trainY.pkl')
save_clean_data(testX,'testX.pkl')
save_clean_data(testY,'testY.pkl')
save_clean_data(eng_length,'eng_length.pkl')
save_clean_data(ger_length,'ger_length.pkl')

Lines 42-52, we save all the variables we received from line 24 as pickle files.

Executing the script

Now that we have completed all the scripts, let us go ahead and execute the scripts. Open a terminal and give the following command line arguments to run the script.

$ python mt_driver_train.py

All the scripts will be executed and finally the model files and other variables will be stored on disk. We will be using all the saved files in the inference phase. We will address the inference phase in the next post of the series.

Go to article 7 of this series : From prototype to production: Inference Process

You can download the notebook for the prototype using the following link

https://github.com/BayesianQuest/MachineTranslation/tree/master/Production

Do you want to Climb the Machine Learning Knowledge Pyramid ?

Knowledge acquisition is such a liberating experience. The more you invest in your knowledge enhacement, the more empowered you become. The best way to acquire knowledge is by practical application or learn by doing. If you are inspired by the prospect of being empowerd by practical knowledge in Machine learning, I would recommend two books I have co-authored. The first one is specialised in deep learning with practical hands on exercises and interactive video and audio aids for learning

This book is accessible using the following links

The Deep Learning Workshop on Amazon

The Deep Learning Workshop on Packt

The second book equips you with practical machine learning skill sets. The pedagogy is through practical interactive exercises and activities.

This book can be accessed using the following links

The Data Science Workshop on Amazon

The Data Science Workshop on Packt

Enjoy your learning experience and be empowered !!!!

Logic of Logistic Regression – Part III



data

In our previous post on logistic regression we defined the concept of parameters and had a first hand glimpse on the dynamics between the data set and the parameters to obtain our first set of predictions. In this part we will go further into how we optimize the parameters in order to improve the accuracy of our predictions. We will be dealing with the following concepts

  1. Deciphering the prediction errors
  2. Minimizing errors through gradient descent and finding optimized parameters
  3. Prediction with the optimized set of parameters.

Deciphering Prediction Errors

Let us revisit the toy example we discussed in our last post and dissect the below table which represented the dynamics of prediction.

activation

To recap, let us list down our discussions in  the last post on the dynamics involved in the above table.

  • We first assumed an initial set of parameters
  • Multiplied the parameters with the respective features ( columns 2,3 &4) to get the weighted sum.
  • Converted the weighted sum into predictions ( column 6) by applying the activation function (sigmoid function).

Let us take a moment to reflect on what the predictions really mean ? The predictions are in fact the probabilities of the customer  buying the insurance policy. For example, for the first customer, we are predicting that the probability that the customer will buy the insurance policy is almost 17.9%.

However when we talk about predictions the first thing which comes to our mind is the veracity of those predictions. How close to reality are the first set of predictions which we made ? If we recall, in our last discussion on the training set, we introduced a new column called the labels. The labels in fact is the reality !! For example looking at the labels column we know that the first two customers did not buy the insurance policy ( label of ‘0’) and the next two bought the insurance policy. The veracity of our predictions can be realized by comparing our predictions with the reality manifested in the labels. By comparing we can see that the first and last customer predictions are somewhat close to reality and the middle ones are pretty off target. In ideal state, we want the first two predictions to be close to zero and the last two pretty close to ‘1’. However, what we predicted have obviously deviated from the reality. Such deviations are the errors we have inherited in our predictions.  However we need to note that the calculation of error for a classification problem like ours is a little mathematically oriented and is not as straight forward as subtracting the probability from the labels. For the sake of simplicity let us not get into those mathematical calculations and stick to our understanding that there  some errors inherited for each example. From the errors of each example we  can find the average error by summing up errors of all examples and dividing it by the number of examples ( 4 in our case). In machine learning parlance the average error so obtained can also be called the ‘Cost’.

Now that we know that there are ‘Cost’ involved in our predictions, our aim should be to minimize the cost so that our predictions are as close to the reality as possible.However the million dollar question is how do we minimize the cost ? What are the levers we have to reduce our costs ? Going back to our toy example, the two entities we have played around to get the predictions are the ‘data’ and the ‘parameters’ . We cannot change the given data because it is fixed. So all we have got to play around with is the parameters which we assumed. We have to try to change our parameters systematically so that we minimize the costs and get our predictions as close to the reality as possible. One of the ways we do this is by a procedure called gradient descent.

Gradient Descent

To understand the concept of gradient descent let us look at some graphical representations.

cost

A pictorial representation of the cost function will look as the above. In the ‘X’ axis we have our parameters and in the ‘Y’ axis we have the cost. From the figure we can see that there are some set of parameters,’P’ with which we can get to the minimum cost ‘C_min’. Our aim is to find those parameters which will give us the minimum cost.

Let us represent the initial parameters we assumed as P_initial. For this set of parameters let us denote the  cost we derived as C1, as given in the figure. We can see from the figure that by moving the P value to the left ( decreasing the parameters ) by some value we can get to the minimum value of cost. Alternatively, if our initial ‘P’ value were to be on the left side of the graph, we would have to move to the right ( increase the value of parameters ) to get to the minimum cost. The procedure for achieving this is called the gradient descent.

The idea behind gradient descent is represented pictorially as below.

gradient_descent

We decrease the parameters by small steps in an iterative fashion so as to get to the minimum cost. To find out  the “small steps” which I mentioned in the previous line we use a trick we learned in high school calculus called partial derivative. By taking the partial derivative at each point of the cost curve we get a value by which we have to reduce the parameters. With the new set of reduced parameters we find the new cost. Again we find the partial derivative at the new cost level to get the next steps which we have to take, and this process continues till we reach the minimum cost. An analogy to this process is like this. Suppose we are on top of a hill, blindfolded, and we want to find our way down the hill. The way we can do this is by feeling the ground with our foot to find those spots which are lower than the ones where we are currently and then move to the new spot. From the new spot we repeat the process till we finally reach the bottom of the hill. Gradient descent works somewhat similar to this.



Summarizing our discussions on gradient descent, these are the steps we take to get the optimum parameters.

  1. First start of with the assumed random parameters.
  2. Find the cost ( errors ) associated with the assumed parameters.
  3. Find the small steps we have to take to alter our parameters, by taking partial derivative of the cost.
  4. Reduce the parameters by the small steps and get a new set of parameters
  5. Find the new cost associated with the new parameters.
  6. Repeat the processes 3,4 & 5 till we get the most optimized cost.

The optimized parameters which we finally get are called the learned parameters.Getting to this optimized parameters is the most involved part of machine learning. Once we learn the parameters using, the training set, we are all set to do predictions which is the objective of any machine learning process.

Doing Predictions

Having learned our set of optimized parameters from the training set, we are now equipped with enough ammunition to do predictions. For doing predictions we take a new set of data called the test set. However there is a difference between the training set and test set. The test set will not have any labels. Our job is to predict the labels from the parameters we have learned. So in the insurance company example, the test set would be the new set of leads which the sales team generated. We have to predict the likelihood of these leads, buying an insurance policy. The way we do the prediction is as follows.

  • We take the optimized set of parameters learned from the training set
  • Multiply the parameters with the respective features ( columns 2,3 &4) to get the weighted sum.
  • Convert the weighted sum into probabilities ( column 6) by applying the activation function (sigmoid function).
  • We take a threshold point ( say 0.5). So any probability less than the threshold point is predicted as ‘0’ ( Will not buy) and anything greater that the threshold point is predicted as ‘1’.

The threshold point which we take to make a decision on our predictions is called the decision boundary.Needless to say, the logistic regression is the basic model among a vast set of powerful classification algorithms. The significance of logistic regression is that it is the building block for the development of powerful algorithms like Support Vector machines, Neural Networks etc. Having said that there are many problem areas where we have to go for simple algorithms like logistic regression. Having dealt with the basic building blocks of classification problems we will have further discussions on some of the most powerful algorithms in future posts. Until then watch out this space for more.

Logic of Logistic Regression – Part II

images

In the first part of this series on Logistic Regression, we set the stage for unveiling the logic behind logistic regression. We stopped our discussion by identifying three dynamic forces at play which determines the quality of predictions,

  1. Weights or parameters which we learn
  2. The activation function, and
  3. The decision boundary

In this second, part of the series we will look deeper into the first two of those dynamic forces.

Concept of Parameters

In the first part of this series when we were discussing the example we assumed a set of parameters i.e W(age) = 8 ; W(income) = 3 and W(propensity) = 10. Quite naturally, a  question lot of people asked me was, where did we get those values from ? Well, as far as that example was concerned, it was just some assumed values. However in the world of machine learning, the parameters is its Holy Grail. The cardinal purpose of the algorithms and theorems of machine learning is to enable the pursuit of the right set of parameters. But why is it that the parameters, so important ? To answer this let us look at what the parameters help us achieve.

Let us revisit the toy data set which we used in the first part. Let us first understand this data set before we get into understanding the parameters.

As can be seen, this data set consists of rows and columns. The data along the columns ( Age, Income & Propensity) are called its  features and the ones along the rows are the examples. In short each customer record in this data set is an example.

Now that we have seen the data set, let us now see the dynamics between the parameters and the data.

The role of the parameter is to act as a weighting factor for each of the features. In other words each feature will have a unique parameter playing the role of a weight. Our example data set has three features and therefore the number of parameters we will have is also three. In general if there are ‘n’ features there should be at least ‘n’ parameters ( However, in practice we will have n+1 parameters where the additional parameter is called the bias term. We will ignore that for the time being).  Please note here that the number of parameters does not depend on the number of examples.

Having looked at the anatomy of the data set and parameters, let us look at how the parameters are learned from a given data set.

Learning Parameters from data

The data set which is used for learning parameters is called a training set. There is a subtle difference between a training set and the one shown above. For the training set we will have an additional column and this additional column is for the labels or dependent variables.

trng

The above data set is an example for a training set. The ‘labels’ column represent the results or outcome for each record. The records with ‘0’ are negative examples and those with ‘1’ are the positive examples. In this context the negative example would mean those customers who did not buy an insurance policy and the positive examples are the ones who bought them. The labels can also be interpreted from the perspective of probability of buying. So all the negative examples are the ones where the probability of sales is low i.e near 0% and the positive ones are those with high probability i.e near 100%. In real life a training set can be made from the historical data of customers in the organisation i.e who are the customers ? How many of them bought a policy ? How many did not ? etc.

The way, we go about the task of learning the parameters from the training set is as follows

  • Random Assumption of Parameters: To start off, we randomly select some arbitrary values for the parameters. For eg. let us assume the following values for the parameters ; W(age) = 1 ; W(income) = 1 and W(propensity) = 1
  • Scaling of the data : Once that we have assumed the parameters let us do some modification on the training data setIf we note the values for each features, the scale of values for each feature vary quite a bit. The values of feature ‘Age’ are all two digit numbers, the values of ‘Income’ are four digit numbers etc. In machine learning, when the values falls within different scales, the accuracy of prediction gets affected. So it is a good practice to normalize the data. One popular way is to subtract each value with the average of the feature and then divide by the range( difference between the maximum value and minimum value). Let us see this in action,with the feature ‘Age’                                                                                                                                           Average value of ‘Age’ = (28+32+36+ 46)/ 4 = 35.5                                                                         Range of ‘Age’ = 46 – 28 = 18                                                                                                                Scaled value for the first data (28) = 28 – 35.5 / 18 = -0.4167                                                  Similarly we do it for the complete data set. The scaled data set is as represented below.    Please note that we do not scale the labels.                                                                                                                                                          scale
  • Prediction with initial parameters : Once the data is scaled,  we go to the next step of using the assumed parameters for prediction. As mentioned earlier, the parameters are like weights which needs to be applied on each feature of the data. Therefore the first step in arriving at a prediction is to multiply the parameters with the corresponding feature and adding up the weighted features for each example. The same is carried out as below. Please note that the labels are not involved in any of these operations.   Weight   Let us study the above column closely. The weighted sum column which is got by applying the parameter on each feature and adding them up, is the value which finally determines the prediction. However for a classification problem the most intuitive way of representing the prediction is in terms of probabilities. As you know, when you represent a value as a probability it has to be within the range of ‘0’ and ‘1’. However if you note our weighted sum column, most of the values are outside the range of 0 & 1. So our challenge would be to apply some mathematical operation to represent them as a probability. The mathematical operation we use for this purpose is called the Activation Function.  One of the most common activation function used in classification problems is the  Sigmoid function . By applying this function on the weighted sum column we convert it into numbers which can be interpreted as probabilities. activation The new data set after applying the activation function is as represented above. Note that the probabilities column is our actual prediction and it can be interpreted as the probability that the  customer will buy the insurance policy. So for the first customer there is only 17.88% chance for buying the policy and for the last customer there is a high chance ( 81.4 %) for him/her to buy the policy.                                                                                                                                                                                                                                   Now that we have seen how we apply the activation function to get the prediction, we are a step closer to our final goal of learning the right parameters which gives the most accurate prediction. This all important step called the gradient descent will be explained in the next part of the post. Please watch out this space for the most important part of our logistic regression problem.

Bayesian Inference – A naive perspective

Many people have been asking me on the unusual name I have given for this Blog – “Bayesian Quest”. Well, the name is inspired from one of the important theorems in statistics ‘The Bayes Theorem’. There is also a branch in statistics called Bayesian Inference whose foundation is  the Bayes Theorem. Bayesian Inference has shot into prominence in this age of ‘Big Data’ and is therefore widely used in machine learning. This week, I will give a perspective on Bayes Theorem.

The essence of Statistics is to draw inference on an unknown population, from samples. Let me elaborate this with an example.  Suppose you are part of an agency specializing in predicting poll outcomes of general elections. To publish the most accurate predictions, the ideal method would be to ask  all the eligible voters within your country  which party they are going to vote. Obviously we all know that this is not possible as the cost and time required to conduct such a survey will be prohibitively expensive. So what do you, as a Psephologist do ? That’s where statistics and statistical inference methods comes in handy. What you would do in such a scenario is to select representative samples of people  from across the country and ask them questions on their voting preferences. In statistical parlance this is called sampling. The idea behind sampling is that, the sample sizes so selected( if selected carefully) will reflect the mood and voting preferences of the general population.  This act of inferring the unknown parameters of the population from the known parameters of the sample is the essence of statistics.There are predominantly two philosophical approaches for doing statistical inference. The first one, which is the more classical of the two is called the Frequentist approach and the second the Bayesian approach.

Let us first see how a frequentist will approach the problem of predictions. For the sake of simplicity let us assume that there are only two political parties, party A and party B.Any party which gets more than 50% of popular votes wins in the election. A frequentist will start their inference by first defining a set of hypothesis. The first hypothesis, which is called the null hypothesis, will ascertain that party A will get more than 50% vote. The other hypothesis, called the alternate hypothesis, will state the contrary i.e. party A will not get more than 50% vote. Given these hypothesis, the next task is to test the validity of these hypothesis from the sample data. Please note here, that the two hypothesis are defined with respect to population(all the eligible voters in the country) and not the sample.

Let  our sample size consist of 100 people who were interviewed. Out of this sample 46 people said they will vote for party A, 38 people said that they will vote for party B and the balance 16 people were undecided. The task at hand is to predict whether party A will get more than 50% in the general election given the numbers we have observed in the sample. To do the inference the frequentist will calculate a probability statistic called the ‘P’ statistic. The ‘P’ statistic in this case can be defined as follows – It is the probability of observing 46 people from a sample of  100 people who would vote for party A, assuming 50% or more of the population will vote for party A. Confused ????? ………….. Let me simplify this a bit more. Suppose there is a definite mood among the public in favor of party A, then there is a high chance of seeing a sample where  40 people or 50 or even 60 people out of the 100 saying that they will vote for party A. However there is very low chance to see a sample with only 10 people out of 100 saying that they will vote for party A. Please remember that these chances are with respect to our hypothesis that party A is very popular. On the contrary if party A were very unpopular, then the chance of seeing  10 people out of 100 saying they will vote for party A, is very plausible. The chance or probability of seeing the number we saw in our sample under the condition that our hypothesis is true is the ‘P’ statistic. Once the ‘P’ statistic is calculated , it is then compared to a threshold value usually 5%. If the ‘P’ value is less than the threshold value we will junk our null hypothesis that 50% or more people will vote for party A and will go with the alternate hypothesis. On the contrary if the P value is more than 5% we will stick with our null hypothesis. This in short is how a frequentist will approach the problem.

A Bayesian will approach this problem in a different way. A Bayesian will take into account historical data of past elections and then assume the probability of party A getting more than 50% of popular vote. This assumption is called the Prior probability.Looking at the historical data of the past 10 elections,  we find that only in 4 of them party A has got more than 50% of votes. In that scenario we will assume the prior probability of party A getting more than 50% of votes as .4( 4 out of 10). Once we have assumed a prior probability, we then look at our observed sample data ( 46 out of 100 saying they will vote for party A) and determine the possibility of seeing such data under the assumed prior. This possibility is called the Likelihood. The likelihood and the prior is multiplied together to get the final probability called the posterior probability. The posterior probability is our updated belief based on the data we observed and also the historical prior we assumed. So if party A has higher posterior probability than party B, we will assume that Party A has higher chance of getting more than 50% of votes than party B. This is rather a very naive explanation to the Bayesian approach.

Now that you have seen both Bayesian and Frequentist approaches you might be tempted to ask which is the better among the two. Well this debate has been going on for many years and there is no right answer. It all depends on the context and the problem which is at hand. However, in the recent past Bayesian inference has gained a definite edge over the Frequentist methods due to its ability to update prior beliefs through observation of more data. In addition, computing power is also getting cheaper and faster making Bayesian inference much more fulfilling than Frequentist methods. I will get into more examples of Bayesian inference in a future post.
